Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales

5858 USD ($)/Set

Get a Price/Quote

Product Details:

Measuring Range Brinell, Rockwell, Vickers scales
Power Supply AC 220V .5 kW / 50 Hz
Equipment Type Hardness Tester
Hardness Displays HB, HV, HR values
Max Height 200 mm (Specimen)
Humidity 085% RH
Response Time <1 sec
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales Price And Quantity

Minimum Order Quantity 1 Set
Price 5858 USD ($)/Set

Safety Overload protection, Emergency stop
Camera Resolution 720P
Software Integrated analysis software with data export
Test Force 1250 kgf
Indenter Types Diamond (Vickers, Rockwell C), Steel Ball (Brinell, Rockwell A/B)
Output Method USB, RS232, Wireless optional
Calibration On-screen digital calibration
Operation Language English / Multi-language support
Compliance Meets ASTM, ISO hardness tester standards
Lighting LED illumination for specimen observation
Backup Battery Optional
Integration Database and printer connectivity

Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales Product Specifications

Operating Voltage AC 220V .5 kW
Test Width 150 mm
Machine Weight 150 kg
Test Speed 0.525 mm/min
Usage Laboratory and Industrial
Mounting Type Bench/Table Mounted
Port Size USB, RS232
Response Time <1 sec
Test Stroke 30 mm
Automation Grade Automatic
Features Data Storage, Statistical Output, Automated Indentation Measurement, Selectable Test Scale
Humidity 085% RH
Control Mode Touch Screen 24 Digital Automatic
Measuring Range Brinell, Rockwell, Vickers scales
Power Supply AC 220V .5 kW / 50 Hz
Equipment Type Hardness Tester
Hardness Displays HB, HV, HR values
Max Height 200 mm (Specimen)
Interface Type USB, RS232
Gas Pressure No external gas required
Temperature 1040 C
Test Range Brinell (HB 5650), Rockwell (HRA, HRB, HRC 2070), Vickers (HV 101000)
Display Type 7 Color Touch LCD
Application Metals, Alloys, Surface Treatment, Quality Control
Frequency 50 Hz
Accuracy 9 25 (Brinell), 0 25 (Rockwell), <1% (Vickers)
Resolution 0.01 HR
Capacity Testing up to 500 samples/day
Specimen Size Max 200 mm height, Max 150 mm width
Number of Specimens 13 pieces per cycle

Safety Overload protection, Emergency stop
Camera Resolution 720P
Software Integrated analysis software with data export
Test Force 1250 kgf
Indenter Types Diamond (Vickers, Rockwell C), Steel Ball (Brinell, Rockwell A/B)
Output Method USB, RS232, Wireless optional
Calibration On-screen digital calibration
Operation Language English / Multi-language support
Compliance Meets ASTM, ISO hardness tester standards
Lighting LED illumination for specimen observation
Backup Battery Optional
Integration Database and printer connectivity

Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Packaging Details Standard export wooden package
Certifications CE FCC

Product Description

Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales

Introduction:

HBRVS-187.5 digital display Blovi hardness tester has 8-inch touch screen intuitive display and single-chip control system, which can realize man-machine dialogue and automatic operation; it has high test accuracy, simple operation, high sensitivity, convenient use, and stable display value; It fully realizes the automatic operation of test force application, removal, and direct display of hardness value. Built-in printer, RS232 interface and USB interface can realize data exchange between computer and hardness tester.

Features:

1.Adopt 8-inch touch screen, display rich content, easy to operate

2.Ready-to-use, no need to install weights

3.Three test methods for Brinell, Rockwell and Vickers hardness

4.Automatic hardness conversion

5.High precision optical system

6.Measurement data U disk saved as EXCEL format, easy to edit and save

7.With RS232 interface, test results can be transmitted to the computer

Scope of application:

Determination of Brinell, Vickers, Rockwell hardness of ferrous metals, non-ferrous metals and hard alloys; Wide range of applications, can be widely used to determine:

a. Brinell hardness of castings, annealed steel, normalized steel, non-ferrous metals and soft alloys

b. Rockwell hardness of heat-treated materials such as quenching, quenching and tempering

c. Vickers hardness of nitriding layer, ceramics, thin plate, metal sheet, electroplating layer and tiny parts.

Specification:

Delay control: adjustable from 0 to 90 seconds

Distance from the center of the indenter to the body: 160mm

Maximum allowable height of the sample: Rockwell 200mm, Brinell Vickers 165mm

Dimensions of the hardness tester (length A width A height): 550 x 230 x 750mm

Approx. weight of the instrument: 89kg

Test force:

Rockwell: 60, 100, 150KGf (588, 980, 1471N)

Brinell: 31.25, 62.5, 187.5Kgf (306.5, 612.9, 1839N)

Vickers: 30, 100Kgf (294.2, 980.7N)

Measuring ruler:

Rockwell: HRA, HRB, HRC, HRD, HRF, HRG

Brinell: HBW2.5/31.25 HBW2.5/62.5 HBW5/62.5 HBW2.5/187.5

Vickers: HV30, HV100

Measuring range:

Rockwell: 20-95HRA, 10-100HRBW, 20-70HRC

Brinell: 5-650HBW

Vickers: 10-2900HV

Magnification: 100X, 50X, 25X

Advanced Multi-Scale Testing

This hardness tester accommodates Brinell, Rockwell, and Vickers methods, enabling comprehensive hardness analysis for a wide range of materials. Multi-scale precision ensures suitability for metals, alloys, and treated surfaces, making it a versatile solution for quality assurance and research laboratories.

User-Friendly Operation

With a 7-inch color touch screen and digital automatic controls, users experience intuitive navigation and can select test scales with ease. Multi-language support and on-screen calibration further simplify operation, promoting efficiency and reducing user errors.

Data Connectivity and Reporting

Integrated data storage and connectivity options, including USB, RS232, and optional wireless, empower seamless data transfer and export. The built-in analysis software and printer/database integration allow for efficient documentation and statistical reporting of test outcomes.

FAQ's of Touch Screen Hardness Tester with Brinell Rockwell Vickers Scales:

Q: How does the Touch Screen Hardness Tester ensure accurate results across Brinell, Rockwell, and Vickers scales?

A: Accuracy is achieved through automated indentation measurement and digital calibration, while compliance with ASTM and ISO standards verifies reliable results for each scale: Brinell (5-650 HB), Rockwell (HRA/HRB/HRC 20-70), and Vickers (HV 10-1000).

Q: What are the benefits of using the integrated analysis software?

A: The integrated software streamlines data recording, analysis, and export, enabling users to quickly evaluate specimen hardness and generate statistical output or reports for quality control, reducing post-test manual processes.

Q: When is it recommended to use the diamond or steel ball indenter types?

A: Diamond indenters are ideal for testing harder materials (Vickers, Rockwell C), while steel ball indenters suit softer materials and scales (Brinell, Rockwell A/B), depending on the application and specimen's hardness range.

Q: Where can this hardness tester be installed for optimal use?

A: It is designed as a bench or table-mounted instrument, suitable for laboratory environments, industrial settings, and quality control facilities with specimen size up to 200 mm height and 150 mm width.

Q: What is the process of calibrating the machine before operation?

A: Users perform on-screen digital calibration via the 7-inch touch LCD, following prompts to ensure the tester's precision and readiness for various hardness scales before starting the test cycles.

Q: How does the safety system protect the operator and equipment?

A: The tester features overload protection and an emergency stop, which safeguards the device and user during operation by preventing mechanical or electrical faults and allowing for immediate halt in emergencies.

Q: What usage capacity and export options are available?

A: The machine can process up to 500 samples per day, outputs data via USB, RS232, or wireless options, and supports both database and printer integration for efficient reporting and archiving.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Hardness Tester' category

Professional Manual Metal Hardness Testing 10 Vicker Hardness Tester Price Range : 1699.00 - 3699.00 USD ($)/Set Minimum Order Quantity : 1 Test Range : 53000 HV Usage : Lab or Industrial Machine Weight : 45 kg Application : Metals Hardness Testing Measuring Range : 53000 HV Power Supply : 220V/50Hz Equipment Type : Vickers Hardness Tester Hardness : Vickers (HV) Humidity : 85% RH Control Mode : Manual Test Stroke : Up to 100 mm Response Time : Instantaneous Automation Grade : Manual Features : Precision indenter, Easy operation, Durable construction Operating Voltage : 220V Test Width : Up to 100 mm Test Speed : Manual (operator controlled) Port Size : Standard Mounting Type : Bench Top Specimen Size : Max 100 mm height Number of Specimens : Single Specimen per Test Resolution : 0.5 HV Capacity : 10 kgf (Vickers Indenter) Display Type : Analog/Dial Accuracy : 3% Temperature : 10C ~ 35C

Send Inquiry

Shore A Hardness Tester Price Hardness Test Machine DH-LX-A Price Range : 199.00 - 499.00 USD ($)/Set Price : 449 USD ($)/Set Minimum Order Quantity : 1 Test Range : Shore A 0100 HA Usage : Material hardness testing Machine Weight : 4 kg Application : Rubber, elastomers, polymers hardness measurement Measuring Range : Shore A 0100 HA Power Supply : None (manual operation) Equipment Type : Shore A Hardness Tester Hardness : Shore A Humidity : 80% Control Mode : Manual Test Stroke : 0 12 mm Response Time : Immediate Automation Grade : Manual Features : Portable, handheld, easy to operate Operating Voltage : Not applicable (manual device) Test Width : 0 60 mm Test Speed : Standard manual application Port Size : Standard sample port Mounting Type : Handheld Specimen Size : Minimum thickness 6 mm Number of Specimens : 1 Resolution : 1 HA Capacity : Designed for rubber and soft polymer materials Display Type : Analog dial Accuracy : 1 HA Temperature : 0C 40C
