E Series Electromagnetic Six-degree Vibration Table

3239.00 - 8990.00 USD ($)/Set

Get a Price/Quote

Product Details:

Hardness Table surface hard anodized aluminium
Gas Pressure 0.6 MPa (if pneumatic table included)
Automation Grade Automatic
Accuracy 1% full scale
Display Type Digital LCD
Power Supply AC 220V, 50Hz
Resolution 0.01 mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

E Series Electromagnetic Six-degree Vibration Table Price And Quantity

Minimum Order Quantity 1 Set
Price Range 3239.00 - 8990.00 USD ($)/Set

Operation Mode Manual & Fully Automatic test modes
Cooling System Natural air cooling
Installation Environment Flat, vibration-free platform
Noise Level 65 dB
Platform Material High-grade aluminium alloy
Excitation Method Electromagnetic force drive, independent 3-axis control
Safety Features Overload and overcurrent protection, Emergency Stop
Signal Output Programmable waveform output
Data Logging Integrated data storage and export capability

E Series Electromagnetic Six-degree Vibration Table Product Specifications

Operating Voltage AC 220V
Response Time 0.2 s
Specimen Size Max. 500 400 mm
Port Size Standard: 25 mm
Interface Type USB / RS232
Equipment Type Electromagnetic Vibration Table
Application Anti-vibration, reliability and fatigue testing for electronics and automotive components
Frequency 5 500 Hz adjustable
Test Width 600 mm
Capacity Max. 120 kg (table load)
Mounting Type Floor-standing with anti-vibration feet
Humidity 85% RH
Number of Specimens 1 4 specimens per cycle
Measuring Range 0.01 2.5 mm (displacement)
Test Speed 0.1 2.0 m/s
Max Height 1300 mm
Test Range X, Y, Z, X, Y, Z Six-dimensional
Temperature 5C 40C
Machine Weight Approx. 250 kg
Display Type Digital LCD
Accuracy 1% full scale
Automation Grade Automatic
Gas Pressure 0.6 MPa (if pneumatic table included)
Control Mode Microcomputer / PLC Automatic Control
Hardness Table surface hard anodized aluminium
Usage Laboratory and industrial
Test Stroke 0 60 mm adjustable
Features Six-degree-of-freedom, programmable waveforms, low noise operation
Resolution 0.01 mm
Power Supply AC 220V, 50Hz

Operation Mode Manual & Fully Automatic test modes
Cooling System Natural air cooling
Installation Environment Flat, vibration-free platform
Noise Level 65 dB
Platform Material High-grade aluminium alloy
Excitation Method Electromagnetic force drive, independent 3-axis control
Safety Features Overload and overcurrent protection, Emergency Stop
Signal Output Programmable waveform output
Data Logging Integrated data storage and export capability

E Series Electromagnetic Six-degree Vibration Table Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

E Series Electromagnetic Six-degree Vibration Table 1-600HZ (Vertical + Horizontal + Front and Rear) DH-VT-500-E2

Application:

Electromagnetic vibration table are widely used in industries such as defense, aviation, communications, electronics, automobiles, home appliances, and others. This type of equipment is used to find early faults, simulate actual working conditions and structural strength tests. The product has a wide range of applications, wide application areas, and significant and reliable test results. Sine wave, frequency modulation, frequency sweep, programmable, frequency doubling, logarithmic, time control.

Features:

1. Using the most advanced and simple operation technology, fixed frequency, frequency sweep, easy to switch the program at any time

2. With function of time timing, countdown displaying

3. Touch controller, simple and convenient operation, solve the shortcomings of inconvenience of digital display operatio

4. The control parameters are displayed synchronously in real time without manual intervention.

5. The base of the machine adopts vibration isolation device, which is easy to install and runs smoothly, without the need to install anchor fixing screws

6. Embedded amplitude prediction program and easy amplitude modulation

7. Four-point synchronous vibration, uniform table vibration

8. Stepless adjustment of amplitude, fixed frequency and frequency sweep operation functions adapt to various test requirements in different industries

9. Add anti-interference circuit to solve the interference of the control circuit due to strong electromagnetic field

10. Curve display function, you can view the frequency waveform changes at any time

11. Curve supports direct export function

12. Automatic switching of working direction

13.Vibration modes in different running directions can work simultaneously

Specification:

Test load:60KG (can custom made for loads over 60kg)

Vibration direction: Vertical + horizontal + front and back (automatic switching, can run different vibration directions at the same time)

Table size (mm): 500*500

Amplitude (P-P): 0-5mm (random, change with frequency, adjustable)

Frequency sweep: 1-600HZ can be set arbitrarily (true standard back and forth frequency sweep) 1-3000HZ can be customized

Maximum acceleration: 20g

Indicator function: FM, frequency sweep, time, program

Accuracy: Frequency can be displayed to 0.1Hz, precision 0.1Hz

Programmable function: 5-600HZ, 1-8 segments can be arbitrarily set frequency and time

Multiplier work (0.1Hz): 8-segment multiplier increase 1.Low to high frequency 2.High to low frequency 3.Low to high and then low frequency/recyclable

Logarithmic work (0.1Hz): 1. Down to up frequency 2. Up to down frequency 3. Down to up then down frequency-3 modes logarithmic/recyclable

Vibration waveform: Sine wave

Time control: Time can be set

Power: 1.2KW

Advanced Six-Degree Testing

Benefit from a comprehensive testing platform capable of simulating six degrees of freedom. The E Series vibration table ensures real-world reliability testing for electronics and automotive parts by simulating a range of dynamic environments. Its independent 3-axis control and programmable waveform output result in unmatched versatility for R&D and quality assurance teams.

Comprehensive Safety & Low Noise

Operate in confidence with built-in safety features-including overload protection, overcurrent protection, and an emergency stop function. The table maintains a quiet working environment (< 65 dB) for laboratories and industrial workspaces, ensuring both operator comfort and test integrity without excessive disturbance.

Intuitive Operation & Data Management

Operate the vibration table manually or automatically, controlled by a user-friendly microcomputer or PLC interface. Integrated data logging and export via USB or RS232 interfaces enable efficient workflow, result analysis, and traceability, supporting modern laboratory and industrial requirements.

FAQ's of E Series Electromagnetic Six-degree Vibration Table:

Q: How does the E Series Electromagnetic Six-degree Vibration Table enable accurate vibration simulations?

A: The table uses electromagnetic force drive and independent 3-axis control to generate programmable multi-directional vibrations over six degrees of freedom (X, Y, Z, X, Y, Z). Its adjustable frequency (5-500 Hz) and displacement (0.01-2.5 mm) ensure precise and customizable simulation of real-world operating environments.

Q: What safety features does the vibration table provide during operation?

A: To ensure operator and specimen safety, the table is equipped with overload and overcurrent protection, as well as an emergency stop button. These features immediately halt operation in case of unforeseen events, protecting both personnel and equipment.

Q: When is it necessary to use a six-degree vibration table, and what components benefit most?

A: Six-degree vibration tables are essential during the development and reliability testing of electronics, automotive, and mechanical components, especially those exposed to dynamic forces. Using this table helps verify product durability and performance under real-world conditions, reducing field failure rates.

Q: Where should the vibration table be installed for optimal performance?

A: Install the vibration table on a flat, stable, and vibration-free surface in a laboratory or industrial environment, within the recommended temperature (5C-40C) and humidity ( 85% RH) ranges. This ensures accurate test results and protects against measurement interference.

Q: What is the process for operating the table and managing test data?

A: Users can select manual or fully automatic test modes using a digital LCD with microcomputer/PLC control. Data are logged and can be easily exported via USB or RS232 interfaces, supporting streamlined reporting and analysis.

Q: How does the integrated data logging feature benefit laboratory workflow?

A: Integrated data storage and export capabilities simplify data collection and analysis, enhancing traceability, documentation, and compliance with test standards. This supports efficient workflow, particularly in R&D and quality assurance environments.
