High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber

839.00 - 1599.00 USD ($)/Set

Get a Price/Quote

Product Details:

Automation Grade Automatic
Application Laboratory, Industrial, Pharmaceutical, Research
Features High vacuum, Uniform heat distribution, Corrosion-resistant chamber
Mounting Type Floor-standing
Humidity Less than 85% RH
Gas Pressure 0.8 MPa
Port Size DN25
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber Price And Quantity

Price Range 839.00 - 1599.00 USD ($)/Set
Minimum Order Quantity 1 Set

Ambient Temperature +5C to +40C
Shelves 2 (adjustable, stainless steel)
Vacuum Level 133 Pa
Safety Features Over-temperature protection, Auto power cut-off
Chamber Material Stainless Steel (SUS 304)
Power Consumption 1200 W
Door Type Toughened Glass with Silicone Seal
Timer 09999 min, digital
Noise Level <60 dB

High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber Product Specifications

Features High vacuum, Uniform heat distribution, Corrosion-resistant chamber
Mounting Type Floor-standing
Gas Pressure 0.8 MPa
Humidity Less than 85% RH
Application Laboratory, Industrial, Pharmaceutical, Research
Automation Grade Automatic
Control Mode Digital PID Controller
Max Height 550 mm
Number of Specimens One (customizable)
Operating Voltage 220V AC
Specimen Size 300300 mm (standard)
Frequency 50 Hz
Port Size DN25
Test Range 0.1 mbar to atmospheric
Capacity 40 L
Display Type Digital LED display
Accuracy 1C
Resolution 0.1C
Machine Weight 65 kg
Interface Type Analog/Digital
Usage Moisture removal, Heat treatment, Dehydration
Test Stroke 300 mm
Temperature Room temperature to 250C
Test Width 400 mm
Equipment Type Vacuum Drying Oven
Measuring Range 0.11013 mbar
Response Time 1 min
Test Speed Adjustable
Power Supply 220V / 50Hz

Ambient Temperature +5C to +40C
Shelves 2 (adjustable, stainless steel)
Vacuum Level 133 Pa
Safety Features Over-temperature protection, Auto power cut-off
Chamber Material Stainless Steel (SUS 304)
Power Consumption 1200 W
Door Type Toughened Glass with Silicone Seal
Timer 09999 min, digital
Noise Level <60 dB

High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber

Usage:

Vacuum drying oven is widely used in biochemistry,chemical and pharmaceutical,health care,agricultural research,environmental protection research.,etc.For powder drying,baking,disinfection and sterilization,especially for the materials of drying heat-sensitive,easily decomposed,easily oxidized and the complex composition to dry quickly and efficiently.

Characteristics:

The shell is made of high quality steel, the surface electrostatic spraying process, the film is firm and beautiful.The working room adopts high quality stainless steel plate for steel plate, semicircular arcs design at the corners, easy to clean
Microcomputer temperature controller with timing, over-temperature alarm etc functions, temperature control accuracy and reliability.
The tightness of the door is completely adjusted by the user with the wholly-shaped silicone seal to ensure the high vacuum in the chamber.
The door is made of double layers bulletproof glass.So the heated materials in the working room is clear at a glance.

B indicates the inner container is stainless steel

DZF-3EB is vertical type and with vacuum pump

Main parameters:

Model: DZF-1

Voltage (V): 220V 50Hz

Rated power(KW): 0.3

Vacuum degree(pa): less than 133

Range of temperature: RT+10-250

Size of workroom (mm)(D*W*H): 300*300*275

overall dimensions (mm) (D*W*H): 430*590*455

Packing(mm) (D*W*H): 590*690*590

number of shelves: 2

Net weight (kg): 43

Gross weight (kg): 50

Superior Build and Safety Features

This vacuum drying oven boasts a corrosion-resistant chamber made from SUS 304 stainless steel and a toughened glass door with a silicone seal. Safety is prioritized through over-temperature protection and auto power cut-off, ensuring safe and consistent operation. The oven's robust construction enables reliable use in laboratories and industrial settings.

Advanced Control and Precision

Equipped with a digital PID controller and LED display, the oven enables precise temperature and vacuum adjustments. The timer is programmable up to 9999 minutes, and adjustable shelves accommodate various specimen sizes. With a measuring range from 0.1 to 1013 mbar, resolution to 0.1C, and accuracy of 1C, it guarantees repeatable results for moisture removal and heat treatment.

Efficient and Versatile Applications

With its high vacuum performance and uniform heat distribution, the oven supports moisture removal, dehydration, and heat treatment for research, laboratory, or industrial purposes. Its floor-standing mounting, large capacity, and automatic operation deliver dependable results for diverse specimen types, making it essential for laboratories and industrial workshops.

FAQ's of High Quality Vacuum Drying Oven Industrial Vacuum Drying Chamber:

Q: How does the vacuum drying oven ensure effective moisture removal from specimens?

A: The oven utilizes a high vacuum environment (133 Pa) and uniform heat distribution within its stainless steel chamber, rapidly extracting moisture even from sensitive materials. The adjustable shelves and PID controlled temperature enable tailored drying for various specimen types.

Q: What safety features are incorporated into the vacuum drying chamber?

A: Safety is ensured with over-temperature protection and automatic power cut-off. The toughened glass door with a silicone seal provides secure containment, while the durable stainless steel chamber resists corrosion, minimizing operational risks during extended laboratory or industrial use.

Q: When is it recommended to use the vacuum drying oven for heat treatment or dehydration?

A: This oven is ideal for processes requiring low humidity and precise temperature control, such as drying pharmaceuticals, heat treating research samples, and dehydrating laboratory specimens. It operates within an ambient temperature range of +5C to +40C and settings between room temperature and 250C.

Q: Where can this vacuum oven be installed and utilized?

A: The floor-standing design allows installation in laboratories, industrial workshops, pharmaceutical facilities, and research institutes. Its robust build, large chamber, and flexible mounting make it suitable for both routine laboratory use and heavy-duty industrial applications.

Q: What is the process for operating the vacuum drying oven?

A: Operation involves loading specimens onto the adjustable shelves, setting temperature and vacuum levels via the digital PID controller, and programming the timer. The oven automatically manages drying cycles with safety cut-offs and displays real-time data through the LED interface.

Q: How does automatic control benefit the usage of this equipment?

A: Automatic features, including the digital PID controller and programmable timer, allow precise adjustments, consistent drying cycles, and enhanced safety. This automation reduces user intervention, enabling efficient and reliable moisture removal and heat treatment.

Q: What are the advantages of the toughened glass door and silicone seal?

A: The toughened glass door offers durability and visibility during drying processes, while the silicone seal maintains high vacuum integrity, preventing leaks and ensuring effective dehydration or heat treatment of samples.
