Model: DHL-90E
Volume: 324L
Internal dimension: 90x60x60(LxWxH) cm
External dimensionAround: 210x125x120(LxWxH) cm
Weight: Around 100Kg
Maximum force: 6KW
Maximum current: 30A
Power supply condition:
1. AC 220V single-phase two-wire + protective grounding; allowable voltage fluctuation range 10%V;
2. The allowable frequency fluctuation range is 500.5Hz; TN-S mode power supply or TT mode power supply;
3. The grounding resistance of the protective earth wire is less than 4;
4. The user is required to configure an air or power switch with corresponding capacity for the equipment at the installation site, and this switch must independently control the use of the equipment
Use environmental conditions:
1. The ambient temperature is 530, and the relative humidity is 85%R.H;
2. The installation site must be a flat and vibration-free ground;
3. The equipment should be kept away from heat sources and flammable and explosive materials;
4. The installation location should not be exposed to direct sunlight, and the indoor air circulation should be maintained;
5. The equipment installation site needs to be clean, and cannot be installed in dusty places or dust outlets, etc.
Temperature and humidity range:
Laboratory temperature: 1080
Pressure tank temperature: RT63
Relative humidity 30%-98%R.H
Heating rate:
Laboratory temperature RT+5060 min
Pressure barrel temperature RT+6360 min
Price:
