DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter

Name: DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 486.0 USD
Availability: InStock

486.0 USD ($)/Set

Get a Price/Quote

Product Details:

Hardness Yes
Features Good Quality
Color Blue
Power Supply Manual
Material Plastic
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter Price And Quantity

Price 486.0 USD ($)/Set
Minimum Order Quantity 1 Set

DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter Product Specifications

Material Plastic
Power Supply Manual
Hardness Yes
Color Blue
Features Good Quality

DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter Trade Information

FOB Port Shenzhen
Payment Terms Paypal, Telegraphic Transfer (T/T), Western Union
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Packaging Details standard exporting package
Main Domestic Market All India

Product Description

DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Gloss Meter for Paper Paint Metal

DH-WG68 gloss meter is produced according to the national verification regulation of JJG696 standard, adopt long life light source, good repeatability, small volume, high precision and good stability. It is mainly used coatings, printing ink, paint, paint, wood, marble, granite, bo to change polishing brick, brick of pottery and porcelain, plastic, paper, metal and non-metallic materials to the surface of the mirror gloss measurement. WG68 for WG268 upgrade, more stable performance, more durable, more comfortable;

Functional Description:

(1) One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incidenct angle of mirror gloss meter is 20, 60, 85 degree respectively;

(2) Optional angle mode: choose measuring angle or angle combination according to user needs.

(3) Manually entering standard samples gloss data;

(4) Humanized design, good man-machine communication interface;

(5)Three angle can store 50000 testing records, storage structure is: 100 prototypes, each prototype with 500 testing data;

(6) Data browsing and viewing function;

(7) The machine has automatic shutdown function, low power warning functions, full data storage hint functions;

(8) USB communication interface to communicate with PC;

(9) PC software can be extended more functions.

Attachment Description:

(1) Power adapter: standard 5V, 2A external power supply;

(2) Standard board: provide calibration criterion.

(3) USB cable: connect instrument to PC.

Specification:

Measuring Angle: 20degree 60degree 85degree

Measuring Range: 20degree:0-2000GU

60degree:0-1000GU

85degree:0-160GU

Measuring Spot

20degree: 10x10mm

60degree:9x15mm

85degree:5x18mm

Measuring Spot: 0-1000:0.1GU 1000-2000:1GU

Zero Error: 0.2GU

Working Temperature Range: 10-40degree

Storage Temperature Range: -10-70degree

Humidity Range: Relative humidity less than 85%,without condensation

Power Adapter: Section 2 5 alkaline batteries/power adapter

Volume: 159x49x72mm

Weight: 500g

Accurate Triple-Angle Gloss Measurement

The DH-WG68 Gloss Meter allows users to measure gloss levels at three industry-standard angles: 20, 60, and 85. This flexibility ensures compatibility with different surfaces, from high-gloss coatings to matte paper and plastic. Accurate readings help maintain product quality and uniformity across manufacturing batches.

User-Friendly and Durable Design

Constructed from high-quality blue plastic, this gloss meter is designed for user convenience and long-lasting performance. Its manual operation and clear digital display simplify the gloss measurement process, making it suitable even for those new to gloss analysis.

FAQ's of DH-WG68 Triangle Gloss Meter 20 60 85 Degree Digital Paper Paint Gloss Meter:

Q: How does the DH-WG68 Triangle Gloss Meter measure gloss on different surfaces?

A: The DH-WG68 operates by projecting light at specified angles (20, 60, 85) onto a surface and measuring the reflected light intensity, providing quantifiable gloss values suitable for paper, paint, and plastic materials.

Q: What are the main benefits of using the DH-WG68 Gloss Meter in quality control?

A: Using the DH-WG68 ensures precise, repeatable gloss measurements, which are crucial for maintaining consistency and product quality in manufacturing and inspection processes.

Q: When should the different measurement angles (20, 60, 85) be used?

A: The 20 angle is best for high-gloss surfaces, 60 for medium-gloss, and 85 for low-gloss or matte finishes, ensuring accurate evaluation tailored to each surface type.

Q: Where is the DH-WG68 Gloss Meter commonly used?

A: This gloss meter is widely used in paper and paint industries, as well as plastic manufacturing and quality testing laboratories, both in China and internationally.

Q: What is the process for using the DH-WG68 Gloss Meter?

A: To use the DH-WG68, calibrate the device using the supplied manual, then place it on the surface to be measured, select the angle, and read the digital display for immediate gloss values.

Q: How does the power supply system support the device's operations?

A: The DH-WG68 is powered manually with reliable supply options, ensuring consistent performance even during extended periods of use in industrial settings.
