DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber

Name: DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 4050.0 USD
Availability: InStock

4050.0 USD ($)/Set

Get a Price/Quote

Product Details:

Features Good Quality
Automation Grade Semi-automatic
Hardness Yes
Material MS
Power Supply Manual
Operating Voltage 110-215 Volt (V)
Usage Hospital & Laboratory
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber Price And Quantity

Price 4050.0 USD ($)/Set
Minimum Order Quantity 1 Set

DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber Product Specifications

Hardness Yes
Automation Grade Semi-automatic
Features Good Quality
Usage Hospital & Laboratory
Display Type LED
Operating Voltage 110-215 Volt (V)
Power Supply Manual
Material MS

DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber Trade Information

FOB Port Shenzhen
Payment Terms Paypal, Telegraphic Transfer (T/T), Western Union
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Packaging Details Standard Exporting Package
Main Domestic Market All India

Product Description

DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber

Introduction:

Differential scanning calorimeter is a touch screen type, which can perform glass transition temperature test, phase transition test, melting and enthalpy value test, product stability, and oxidation induction period test.

Standards:

GB/T 19466.2-2004/ISO 11357-2:1999 Part 2: Determination of glass transition temperature

GB/T 19466.3-2004/ISO 11357-3:1999 Part 3: Determination of melting and crystallization temperature and enthalpy

GB/T 19466.6-2009/ISO 11357-3:1999 Part 6: Determination of Oxidation Induction Time and Oxidation Induction Temperature

Technical parameters:

Temperature range: room temperature-500 degree
Temperature resolution: 0.01 degree
Heating rate: 0.1-100 degree/min
Constant temperature time: recommended <24h
Temperature control method: heating, constant temperature (automatic program control)
DSC resolution: 0.01mW
DSC sensitivity: 0.01mW
Working power supply: AC220V/50Hz or customized
Atmosphere control gas: nitrogen, oxygen (automatic switching of the instrument)
Gas flow: 0-300mL/min
Gas pressure: 0.2MPa
Display mode: 15-inch LCD touch screen display
Data interface: standard USB interface
Parameter standard: Equipped with standard substances (indium, tin, zinc), users can calibrate the temperature by themselves

Features:

1. The industrial-grade 15-inch touch screen is completely free from the constraints of the computer.

2. Electronic flowmeter, record flow more accurately.

3. Independent of the displayed touch interface, more flexible.

4. Unique furnace body sealing can provide good experimental conditions.

5. Automatically switch the two-way atmosphere flow, the switching speed is fast, and the stabilization time is short. At the same time, a protective gas input is added.

6. The software is simple and easy to operate.

Accurate Thermal Analysis for Research and Quality Control

The DH-DSC-500Q Differential Scanning Calorimeter delivers reliable thermal analysis data crucial for materials research, product development, and quality assurance. Designed for hospital and laboratory use, it facilitates accurate measurements to assess the thermal stability and properties of plastics and rubber. Its sturdy MS frame and advanced display support frequent usage in demanding settings.

User-Friendly Operation and Versatility

This semi-automatic calorimeter is tailored for ease of use, accommodating both experienced technicians and newcomers. Its manual power supply and intuitive LED display simplify operation, while adjustable settings cater to varied sample requirements, making it a versatile tool for a wide range of scientific applications involving different polymers and elastomers.

FAQ's of DH-DSC-500Q Differential Scanning Calorimeter for Plastic Rubber:

Q: How is the DH-DSC-500Q Differential Scanning Calorimeter used in hospital or laboratory settings?

A: The device is employed to study the thermal properties of plastics and rubber samples by measuring heat flow as the sample is heated or cooled, which helps in material identification, quality control, and research in hospitals and laboratories.

Q: What are the benefits of using this semi-automatic calorimeter for plastic and rubber analysis?

A: The semi-automatic operation streamlines sample testing while maintaining precision, and the LED display provides clear and immediate access to results. It also offers robust construction and consistent performance, ideal for repeated scientific use.

Q: When should I consider using the DH-DSC-500Q calorimeter in my laboratory?

A: You should use this calorimeter when you require precise thermal analysis of plastic or rubber materials, especially for tasks such as quality assurance, material development, or validating regulatory compliance in scientific or medical settings.

Q: Where can the DH-DSC-500Q Differential Scanning Calorimeter be installed?

A: This instrument is suitable for installation in research laboratories, hospital diagnostic centers, polymer testing facilities, and academic institutions, provided a compatible voltage supply and safe operating environment are available.

Q: What is the process for performing a test using this calorimeter?

A: Place the prepared sample in the calorimeter, set the desired temperature profile, and initiate the semi-automatic measuring process. The LED display will show real-time data for analysis, and manual controls allow for precise adjustment throughout the procedure.

Q: How does the DH-DSC-500Q ensure the quality and reliability of test results?

A: Its sturdy MS material construction and high build quality offer long-term durability and consistent operation. The advanced LED display and calibration capabilities further support accurate and reproducible measurements.
