Ultrasonic Portable Digital Ultrasonic Flaw Detector Supplier
799.00 - 1599.00 USD ($)
Product Details:
- Frequency 0.5 to 20 MHz
- Number of Specimens Single/Multiple
- Power Supply Lithium Battery / AC Adapter
- Equipment Type Digital Ultrasonic Flaw Detector
- Application Weld Inspection, Metal Flaw Detection, Forging & Casting Evaluation
- Specimen Size Varies upon application
- Response Time Instantaneous (<1s)
- Click to view more
X
Ultrasonic Portable Digital Ultrasonic Flaw Detector Supplier Price And Quantity
- 799.00 - 1599.00 USD ($)
- 1 Set
- Audible/Visible Defect Alarm
- 100-400V adjustable
- Up to 5000 A-scans
- Lemo-01/Custom
- Supported
- 240 x 150 x 40 mm
- Multi-language
- IP65 Rated
- Up to 10 hours continuous use
- 0~110 dB
Ultrasonic Portable Digital Ultrasonic Flaw Detector Supplier Product Specifications
- Ultrasonic flaw detector Kilogram(Kg)
- 0.1 mm
- 0.01 mm
- 5 Kilograms (kg)
- DC 7.4V (Battery) / AC 220V
- 0~10000mm (steel)
- Handheld
- Portable, Memory Storage, High Sensitivity, Real-Time Display
- USB
- 0~10000mm (steel equivalent)
- 5.7 high-contrast LCD
- USB, RS232
- <90% RH (non-condensing)
- -10C to 50C
- Industrial Testing
- Varies upon application
- Manual
- Instantaneous (<1s)
- Adjustable (depends on inspection)
- Digital
- Weld Inspection, Metal Flaw Detection, Forging & Casting Evaluation
- Lithium Battery / AC Adapter
- Digital Ultrasonic Flaw Detector
- Single/Multiple
- 0.5 to 20 MHz
- Audible/Visible Defect Alarm
- 100-400V adjustable
- Up to 5000 A-scans
- Lemo-01/Custom
- Supported
- 240 x 150 x 40 mm
- Multi-language
- IP65 Rated
- Up to 10 hours continuous use
- 0~110 dB
Ultrasonic Portable Digital Ultrasonic Flaw Detector Supplier Trade Information
- shenzhen
- 300 Set Per Month
- Days
- standard exporting package
- All India
Product Description
Specification:
- Thickness Measuring Range: 0 - 10000mm
- Scanned Area: 0 - 10000mm
- Frequency Range: 0.5 - 15MHz
- Sound Speed: 1000 - 15000m/s
- Gain: 0 - 120dB
- Measurement Mode: Single, dual, thru
- Resolution: 0.1mm(2.5mm - 100mm) 1mm(>100mm)
- Power: Li-battery (working time>10 hours)
- Display: LED true color
- Humidity: 20% - 90%RH
- Temperature: -20 - 70 degree
- Size: 238*155*46mm
- Weight: 1kg
Features:
- KUT 650 could measure item's thickness, measuring range:0-10000mm
- Automated display precise flaw location(Depth d, level p,distance s,amplitude,sz dB,N ), automated to switch;
- Automated calibration of transducer Zero-point, angles, front edge and material velocity;
- Convenient to make and use DAC/TCG and AVG to evaluate the echo, the curve can be modified and compensated;
- 6dB DAC functions, standards of test for DAC is saved;
- Gate and DAC alarm, display freeze;
- B scan, AWS D1.1;
- Max 500 independence setup, any criterion can be input freely, can work in the scene without test block;
- Big memory Max 1000 A graph, unlimited of video time, automated make video of test process and play;
- Automated gain and gain scan;
- Peak hold and peak memory;
- Powerful PC software,reports can be export to excel;
- The embedded software can be online updated;
- Automated echo degree;
- Big memory Max 1000 A graph;
- Electronic clock calendar, lock and unlock function of system parameters;
- Two gates setting and alarm indication.
Advanced Flaw Detection for Industrial Applications
Engineered for critical applications like weld inspection, forging, and casting evaluation, this portable digital ultrasonic flaw detector excels in a wide range of industrial environments. Its versatile measuring range of 0~10,000mm (steel equivalent) and high-frequency response (0.5-20 MHz) ensure reliability and precision, even for demanding tasks. It is ideal for quality control, maintenance, and research roles within factories, pipelines, and manufacturing plants.
Robust Construction and Superior Usability
Built with an IP65-rated enclosure, this flaw detector withstands harsh industrial settings, resisting dust, moisture, and vibration. It boasts a lightweight, ergonomic design for handheld use, a powerful lithium battery supporting up to 10 hours of continuous operation, and intuitive controls easily navigated via a high-contrast LCD display. The unit's large data storage and multi-language menu cater to diverse workplace needs.
Comprehensive Connectivity and Smart Features
Equipped with standard Lemo-01/custom transducer connectors, USB and RS232 interfaces, this flaw detector ensures smooth PC connectivity and data transfer. Instantaneous response time (<1s) and real-time display facilitate efficient operations. Memory storage for thousands of scans and both visible and audible alarms further simplify analysis, making it suitable for single or multiple specimen testing scenarios.
FAQ's of Ultrasonic Portable Digital Ultrasonic Flaw Detector Supplier:
Q: How does the portable digital ultrasonic flaw detector improve flaw detection accuracy in industrial inspections?
A: The device uses high-sensitivity electronics, an adjustable gain (0-110 dB), and a precise pulser voltage (100-400V) to ensure clear detection of flaws like cracks and inclusions, delivering results with an impressive 0.1 mm accuracy and 0.01 mm resolution across a broad measuring range (up to 10,000 mm in steel).Q: What industries and applications benefit most from this ultrasonic flaw detector?
A: It is ideal for industries requiring thorough quality control, such as shipbuilding, automotive, oil & gas, railways, and construction. The unit is specifically designed for weld inspection, metal flaw detection, and evaluation of forged or cast components.Q: When should I use the memory storage and alarm features during testing?
A: Use the memory storage feature when you need to record up to 5000 A-scan results for subsequent analysis, documentation, or reporting. The audible and visible alarms should be activated to alert operators immediately upon detection of a defect, ensuring rapid response during continuous inspections.Q: Where can the ultrasonic flaw detector be efficiently employed?
A: Thanks to its portable design, IP65 enclosure, and robust operating temperature range (-10C to 50C), this detector is suitable for use in factories, manufacturing plants, construction sites, and field locations requiring on-the-spot material quality assessment.Q: What is the process for connecting the device to a computer for data management?
A: You can connect the detector to a PC using the USB or RS232 port. Once connected, saved data such as A-scans can be transferred easily for analysis or archiving, supporting streamlined reporting and quality assurance processes.Q: How do I operate the flaw detector for extended periods without interruption?
A: The detector is powered by a reliable lithium battery, delivering up to 10 hours of continuous use. For stationary applications, you may use the included AC adapter to ensure uninterrupted operation throughout longer inspection cycles.Tell us about your requirement
