Scott Volumeter Apparent Density Tester Meter

499.00 - 999.00 USD ($)

Get a Price/Quote

Product Details:

Features Stainless steel construction, easy to dismantle and clean, precision funnel
Temperature 15C to 40C operating range
Application Determination of apparent density of free-flowing powders (metallic/non-metallic)
Number of Specimens Single specimen per test
Power Supply Not required (manual type)
Max Height Approx. 300 mm
Display Type Graduated glass cylinder (visual measurement)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Scott Volumeter Apparent Density Tester Meter Price And Quantity

Price Range 499.00 - 999.00 USD ($)
Minimum Order Quantity 1 Set

Scott Volumeter Apparent Density Tester Meter Product Specifications

Mounting Type Bench-top
Capacity Up to 250 ml (graduated measure)
Display Type Graduated glass cylinder (visual measurement)
Features Stainless steel construction, easy to dismantle and clean, precision funnel
Temperature 15C to 40C operating range
Machine Weight Approximately 5.5 kg
Test Speed Manual operation
Usage Laboratory, industrial, research
Max Height Approx. 300 mm
Power Supply Not required (manual type)
Number of Specimens Single specimen per test
Application Determination of apparent density of free-flowing powders (metallic/non-metallic)
Control Mode Manual
Test Range 0.05 to 2 g/cm apparent density
Equipment Type Apparent Density Tester (Scott Volumeter)
Automation Grade Manual
Accuracy 0.01 g/cm
Humidity 10% to 85% RH, non-condensing
Resolution 0.01 g/cm
Response Time Immediate/manual reading
Port Size Standard funnel opening (as per Scott Volumeter specifications)
Hardness Not specified (dependent on material construction)
Specimen Size As per ASTM B329 (typically 25-50g sample)
Measuring Range 0.01 to 3 g/cm

Scott Volumeter Apparent Density Tester Meter Trade Information

FOB Port shenzhen,guangzhou
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

Scott Volumeter Apparent Density Tester Meter

Principle:

Place the powder into the upper mesh sieve, flow into the clothing box by the nature or outside force, powder flow into four pcs glass baffles and square funnel with angle 25 degree, at last flow into sample receiving cup, it is in the bulk type. Customer can weigh the powder weight in the cylindrical receiving cup;

Scott Volumeter (Bulk Density Tester) is designed and produced according to GB5060-85 " Metal Powder Density Testing Second part: Scott Volumeter", it is also in accordance with International standard ISO 3932/2"Metal Powder Bulk Testing Second part: Scott Volumeter",It is suitable for powder can not flow into funnel freely with opening size at 5mm or the powder characteristic will be charged during vibrating funnel;

Feature:

1. Stainless Steel top funnel: it is composed by two pcs Stainless Steel Conical funnel, separate by the cylinder, inside with the opening size 1.18mm Stainless Steel sieve;

2. Clothing box: cross section is square shape, there are 4 pcs 1 mm thick Stainless steel board slide on the Aluminium frame inside; Inside and outside frame, there is Plexiglas plate, Stainless steel board can take off, it is easy to clean and wash

3. Square shape funnel: it is welded by 1mm Stainless Steel board, angle is 60 degree square conical shape, upper dia. is 12.5mm*12.5mm;

4. Cylindrical receiving cup: volume is 25ml, Stainless steel, net weight is 46g;

5. Steel frame: it holds upper assembly funnel, clothing box, square funnel, cylindrical receiving cup;

6. Balance: it weights powder sample, maximum capacity is 1kg,accuracy is 0.02g (optional parts)

Optimal Accuracy in Powder Density Measurement

The Scott Volumeter is engineered to provide superior measurement accuracy for apparent density in powders. Its graduated glass cylinder allows precise visual readings with a resolution of 0.01 g/cm and accuracy of 0.01 g/cm. The four-baffle system helps ensure complete powder de-aeration before measurement, contributing to reliable, repeatable results every time.

Robust and User-Friendly Design

Constructed from polished stainless steel with acrylic or borosilicate glass components, this apparatus is highly durable and easy to clean. Its manual operation requires no power supply, supporting flexibility in laboratory and industrial environments. Dismantling and reassembly is straightforward, making maintenance simple and ensuring consistent performance.

FAQs of Scott Volumeter Apparent Density Tester Meter:

Q: How does the Scott Volumeter Apparent Density Tester operate?

A: The Scott Volumeter is a manual device that measures the apparent density of powders by allowing a sample to flow through a precision funnel into a graduated cylinder, where the volume is read directly. The process uses a four-baffle system which ensures the powder is properly de-aerated before collecting in the cylinder.

Q: What types of materials can be tested with this apparatus?

A: This instrument is suitable for free-flowing powders, including both metallic and non-metallic materials. It is commonly used in laboratories, industrial settings, and research applications that require density measurements conforming to standards ASTM B329 and ISO 3923-1.

Q: Where is the Scott Volumeter typically used?

A: The Volumeter is designed for use in laboratory, research, and industrial environments, especially where accurate powder density determination is essential. Its bench-top mounting and robust build make it suitable for testing facilities and production control labs.

Q: What is the process for conducting an apparent density test with this equipment?

A: A sample (typically 25-50g as per ASTM B329) is weighed, poured into the funnel, and passed through the four-baffle system to the graduated cylinder. The powders volume is then read visually, and the apparent density is calculated by dividing the mass by the measured volume.

Q: When should this tester be used?

A: Use the Scott Volumeter whenever you require precise and repeatable measurement of the apparent density of free-flowing powders, such as for quality control, formulation, or research in metallurgy or material science.

Q: What is the benefit of using the Scott Volumeter Apparent Density Tester Meter?

A: This device provides immediate, accurate results without needing electricity or complex electronics. Its design minimizes sample handling errors and supports compliance with international standards, making it highly valuable for consistent density measurement.
