Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader

1199.00 - 2599.00 USD ($)/Set

Get a Price/Quote

Product Details:

Operating Voltage DC 3.7V (battery operated)
Interface Type Bluetooth & USB
Port Size Micro USB charging port
Measuring Range L*a*b*, RGB, HEX, CMYK
Power Supply Rechargeable Lithium-ion Battery
Application Laboratory, paint matching, printing, textiles, quality control
Mounting Type Handheld
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader Price And Quantity

Minimum Order Quantity 1 Set
Price Range 1199.00 - 2599.00 USD ($)/Set

Battery Life Over 10,000 readings per charge
Accessories Included Charging cable, calibration cap, carrying pouch, user manual
Supported OS iOS, Android, Windows
Calibration Method Built-in white calibration cap
Color Reproducibility High alignment, repeatability E <0.5
Storage Temperature -20C to 50C
Charging Time Approx. 2 hours
Dimension 30mm x 30mm x 105mm
Language Options Multi-language interface
Light Source LED, D65 standard
Body Material ABS premium plastic
Data Storage Internal memory (up to 1000 measurements)
Materials Compatible Textiles, plastics, coatings, paper, liquids (with accessories)
Color Models Supported L*a*b*, RGB, HEX, CMYK, Yxy

Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader Product Specifications

Temperature 0C to 40C (operating)
Control Mode Button / Smartphone App
Machine Weight About 120g (including battery)
Interface Type Bluetooth & USB
Operating Voltage DC 3.7V (battery operated)
Power Supply Rechargeable Lithium-ion Battery
Test Speed 1 second per measurement
Measuring Range L*a*b*, RGB, HEX, CMYK
Equipment Type Portable Multifunctional Color Analyzer Colorimeter
Port Size Micro USB charging port
Usage Color analysis, laboratory measurements
Response Time 1 second
Capacity Unlimited readings with memory
Display Type Digital LCD and Mobile App
Automation Grade Semi-automatic
Mounting Type Handheld
Application Laboratory, paint matching, printing, textiles, quality control
Test Range Visible color spectrum
Humidity <85% (non-condensing)
Number of Specimens Single, per measurement
Resolution 0.01 units
Features Portable, multifunctional, rechargeable, wireless data transmission
Accuracy E < 1.0
Specimen Size Minimum 8mm diameter

Battery Life Over 10,000 readings per charge
Accessories Included Charging cable, calibration cap, carrying pouch, user manual
Supported OS iOS, Android, Windows
Calibration Method Built-in white calibration cap
Color Reproducibility High alignment, repeatability E <0.5
Storage Temperature -20C to 50C
Charging Time Approx. 2 hours
Dimension 30mm x 30mm x 105mm
Language Options Multi-language interface
Light Source LED, D65 standard
Body Material ABS premium plastic
Data Storage Internal memory (up to 1000 measurements)
Materials Compatible Textiles, plastics, coatings, paper, liquids (with accessories)
Color Models Supported L*a*b*, RGB, HEX, CMYK, Yxy

Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader

Aperture (caliber) Application:

Caliber 4mm: Small area, cambered surface. Great convenience to measure small devices, small parts and special type of arc.

Caliber 8mm: Usual Flat surface materials. Great convenience and trustworthy reliability for its versatility, tiny table difference, and stability.

Caliber 16mm: Textured object, pitting, grainy surface or relatively large size, flexible , soft, wet samples, and Powder, Liquid, Granule, Pulp etc.

Colorimeter Application:

Colorimeter can be applicable in textile, printing and dyeing, clothing, footwear, leather, chemicals, plastics, film, pigments, paints, inks, metal, photography, toys, food medicine and other liquid, powder and special industryfor color quality control, color analysis, sample testing, production line testing, also suitable for injection molding, ink, paint, spray and other color industries.

Specification:

Model: DH-WF32

Display Mode: CIELAB, CIELCH, CIEXYZ, CIELUV, HunterLAB, sRGB

Color Difference Formula: E*ab, ECMC, EISO, ECIE94, EFCM, ELuv, Ehunter, EsRGB

Yellowness and Whiteness: Ganci whiteness, ISO brightness, YI yellowness

Illumination Condition: CIE Recommendationi 8/d 45/0 Optional

Light Source: LED blue excitation

Sensor: Photodiode array

Measurement Caliber: 4mm/8mm/16mm Alternative

Measurement ConditionObserver: CIE 10 degree Standard observer

Light source: A C D50 D65 F2(CWF) F7 F11(TL84) F12(U30)

Contain light way: SCI SCE

Measurement RangeL: 0 to 100

Measurement Interval: 0.5 Sec.

Average Measuring Function Average measuring frequency: 1-32 times

Color Simulation Function: yes

Superior Color Measurement Versatility

This colorimeter provides high-precision color analysis for a variety of materials such as textiles, plastics, paper, and even liquids (with accessories). Its agile design ensures accurate color readings in demanding laboratory and industrial applications, opening up versatility across multiple industries.

User-Friendly and Portable Design

Crafted from premium ABS plastic and weighing just 120g, this handheld device features a built-in calibration cap, internal memory for up to 1,000 measurements, and seamless connectivity via Bluetooth and USB. Its interface supports several languages and provides easy control through both digital displays and a smartphone application.

Reliable, Long-lasting Performance

Engineered for efficiency, the rechargeable lithium-ion battery delivers over 10,000 readings per charge with only about 2 hours of charging. The analyzer stores results securely and allows for quick successive measurements, ensuring swift and reliable operation throughout extensive laboratory or quality control shifts.

FAQ's of Portable Multifunctional Color Analyzer Colorimeter Lab Color Reader:

Q: How does the built-in calibration cap ensure measurement accuracy?

A: The built-in white calibration cap allows users to re-calibrate the colorimeter before each session, ensuring high color accuracy and repeatability (E < 0.5) by compensating for any drift or environmental change.

Q: What types of materials can this colorimeter analyze?

A: This device is capable of measuring textiles, plastics, coatings, paper, and-with the right accessories-even liquids, making it suitable for diverse laboratory and industrial needs.

Q: When should I recharge the device, and how long does it take?

A: Recharge the device when the battery is low; it supports over 10,000 readings per full charge and only requires about 2 hours to fully recharge via the included micro USB cable.

Q: Where can I save and review my color measurement data?

A: You can store up to 1,000 measurements on the device's internal memory or transfer unlimited readings to your smartphone or computer via Bluetooth or USB for further analysis and record-keeping.

Q: What is the process for taking a color measurement?

A: Simply turn on the analyzer, perform a calibration with the built-in cap, select your preferred color model, position the device on the specimen (minimum 8mm diameter), and press the button or use the smartphone app; the measurement is completed within 1 second.

Q: What are the benefits of using this portable color reader for laboratory applications?

A: Its portable and semi-automatic design, rapid test speed, precise color matching (accuracy E < 1.0), and compatibility with various color models ensure reliable results in a broad range of laboratory and industrial settings.

Q: How does the multi-language interface enhance usability?

A: The multi-language interface allows users globally to navigate and interpret data efficiently, reducing training time and ensuring consistent user experience across different regions.
