Application:
oil content,powder metallurgy,electric tools,air tools,mechanical parts,fan industry,motor industry,micro-motor,electrical industry,new materials researching laboratory.
Standards:
In accordance with GB/T5165,ISO 2737,GB/T5164,ISO 2738,ASTM B311,B328,GB/T5163,JIS Z2505,JIS Z2506,MPIF Standard42,MPIF Standard45...
Oil content can be displayed by three procedure.it has changed the manual computation method;save time,quick,convenient;it is very suitable to test oil content for copper-base,iron-base,iron copper-base of transmission parts.
Measuring resolution:
AU-120V,AU-200V density resolution:0.0001g/cm3,oil content resolution:0.1%
AU-300V,AU-600V,AU-900V,AU-1200V density resolution:0.001g/cm3,oil content:0.01%
Function and Feature:
1.Easy operation,accuracy,reliability
2.Oil content,density,oil total volume,oil volume can be read directly.
3.Either water or liquid can be used as medium.
4.Adopt completed injection moulding transparent PC water tank(length 15.3cm x width 10.7cm x 9.3cm),which can resist wear,fall off,and corrosion.
5.Function of actual water temperature setting,measuring medium density setting,air buoyancy compensation setting,density top and bottom limitation setting.
6.Equipped special windproof dustproof cover,which makes the structure more convenient and durable.
7.Including RS - 232C communication interface.it is convenient to connect PC with printer.DE-40 can be chose to print measuring data.
8.Gross weight/Size:4.5kg/length 42.5cm x width 17.5cm x height 32.5cm
9.Power supply:AC 100V-240V 50HZ/60HZ Europe standard
Oil length measuring procedure:
1.Place oil sample on testing board to measure weight in air.press ENTER key to memory.
2.Place sample into water,press ENTER key to memory.
3.After oil wiped off,place sample on testing board to measure weight.press ENTER key to memory.oil content will be displayed.
