Metal Coating Thickness Tester Metal Coating Thickness Meter

Metal Coating Thickness Tester Metal Coating Thickness Meter

199.00 - 599.00 USD ($)

Get a Price/Quote

Product Details:

Power Supply 2 x 1.5V AA Batteries
Resolution 0.1 m
Temperature 0C ~ 40C
Specimen Size Minimum 20 x 20 mm
Test Range 0~1500 m (0~59 mil)
Application Measuring metal coating and paint thickness
Mounting Type Handheld
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Metal Coating Thickness Tester Metal Coating Thickness Meter Price And Quantity

Price Range 199.00 - 599.00 USD ($)
Minimum Order Quantity 1 Set

Auto Power Off Yes
Data Hold Function Yes
Probe Type Magnetic Induction and Eddy Current
Low Battery Warning Yes
Backlight Yes
Suitable Materials Ferrous and Non-ferrous Substrates
Storage Temperature -10C ~ 50C
Calibration Method Foil Calibration
Operational Language English
Carrying Case Included

Metal Coating Thickness Tester Metal Coating Thickness Meter Product Specifications

Equipment Type Digital Coating Thickness Meter
Accuracy (3%+1 m)
Machine Weight 5 Kilograms (kg)
Humidity 85% RH
Interface Type No external interface
Usage Portable measurement
Automation Grade Manual
Features Auto standby, low battery indicator, single/continuous mode
Number of Specimens Single Measurement
Display Type LCD Digital Display
Measuring Range 0~1500 m
Operating Voltage 3V (2 x 1.5V Batteries)
Capacity Coating Thickness Tester Kilogram(Kg)
Mounting Type Handheld
Test Width Depends on probe coverage
Control Mode Electronic
Response Time 1 second
Specimen Size Minimum 20 x 20 mm
Test Range 0~1500 m (0~59 mil)
Test Speed Manual Operation
Temperature 0C ~ 40C
Power Supply 2 x 1.5V AA Batteries
Resolution 0.1 m
Application Measuring metal coating and paint thickness

Auto Power Off Yes
Data Hold Function Yes
Probe Type Magnetic Induction and Eddy Current
Low Battery Warning Yes
Backlight Yes
Suitable Materials Ferrous and Non-ferrous Substrates
Storage Temperature -10C ~ 50C
Calibration Method Foil Calibration
Operational Language English
Carrying Case Included

Metal Coating Thickness Tester Metal Coating Thickness Meter Trade Information

FOB Port shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Packaging Details standard exporting package
Main Domestic Market All India

Product Description

Metal Coating Thickness Tester Metal Coating Thickness Meter

KCT300 is capable to measure thickness of non-magnetic coating layers covered on magnetic substrate. Such as: non-magnetic (aluminum, chrome, copper, enamel, paint) covered on magnetic substrate (steel, alloy and magnetic stainless steel), also can measure thickness of non-conductive coatings layers covered on conductive substrate. Such as: (enamel, rubber, paint, plastic) covered on conductive substrate (aluminum, brass, zinc and nonmagnetic stainless steel);

Features:

Various probes optional, probe auto matching;
Durable ruby probe, more wear and precise;
Full metal shell design, sturdy, portable, high reliability;
Alarm function when overrun the settable limiting range;
Five statistics values [MEAN, MAX, MIN, NO., S.DEV] higher measurement accuracy;
Large storage, easy to delete single or multiple saved values;
PC software optional, convenient the data transmission, analysis, printing etc.

Specification:

Measuring Range: Standard 0-1250um (MAX 10000um with probe F10)
Working Principle: Magnetic & Eddy
Substrate: FE / NFe base, depends on probes
Display: 128*64 LCD with backlight
Memory: 5 files x 99 values
Working Temperature: Operation Temp. :-10-50 degree Storage Temp.:-30-70 degree
Power: AA battery 2pcs (Non-aviation transport)
Size: 125*67*31mm
Weight: 340g

Accurate and Versatile Coating Measurements

Engineered for both ferrous and non-ferrous substrates, this thickness tester leverages advanced magnetic induction and eddy current technology to deliver accurate results. Suitable for a variety of metal coating and paint thickness applications, it meets the needs of quality control, maintenance, and production environments.

User-Friendly Operation and Advanced Features

This tester ensures effortless usability with features such as foil calibration, backlight LCD, and auto power off. Operators benefit from portability, a durable carrying case, and straightforward electronic controls, supporting both single and continuous measurement modes for various testing requirements.

Robust Build Designed for Reliability

With a sturdy handheld design and an operational temperature range from 0C to 40C, this tester withstands demanding industrial environments. The device operates on simple AA batteries and has built-in low battery alerts, making it dependable for extensive use without frequent interruptions.

FAQ's of Metal Coating Thickness Tester Metal Coating Thickness Meter:

Q: How does the Metal Coating Thickness Tester measure coating thickness?

A: The device uses magnetic induction for ferrous substrates and eddy current technology for non-ferrous substrates. This allows precise, non-destructive measurement of metal coating and paint thickness, displayed quickly on the digital LCD.

Q: What materials can this tester be used on?

A: It is suitable for measuring coatings on both ferrous (iron, steel) and non-ferrous (aluminum, copper, etc.) metal substrates, offering broad application across manufacturing and maintenance industries.

Q: When should I calibrate the tester and how is it performed?

A: Calibration is recommended before initial use and periodically to maintain accuracy. The device uses a foil calibration method, allowing you to calibrate easily by following the included instructions with calibration foils.

Q: Where can I use this coating thickness meter?

A: The portable, handheld design and robust carrying case make it suitable for field inspections, laboratory measurements, and on-site quality assurance in various industrial settings.

Q: What is the process for measuring a coating's thickness?

A: Simply place the probe on the coated surface, and the device provides a digital reading within one second. The tester supports both single and continuous measurement modes, depending on your needs.

Q: What are the main benefits of using this tester?

A: Benefits include high measurement accuracy (3%+1 m), quick response, ease of use, backlit LCD for visibility, auto standby, low battery warning, and a portable form factor for flexible use.

Q: How is data stored or viewed on this equipment?

A: The tester features a data hold function to retain the most recent reading on the display. There is no external data interface; all results are viewed directly on the digital LCD screen.
