Laboratory Temperature and Humidity Test Chamber

999.00 - 5999.00 USD ($)

Get a Price/Quote

Product Details:

Number of Specimens 1-10 (varies by size)
Equipment Type Laboratory Temperature and Humidity Test Chamber
Interface Type RS232/USB (optional)
Response Time Instantaneous readout, stabilization in 20 minutes
Max Height Internal 650 mm
Temperature 0C/-20C/-40C/-60C/-70C~+100C(+150C)
Display Type Digital LCD Touch Screen
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Laboratory Temperature and Humidity Test Chamber Price And Quantity

Minimum Order Quantity 1 Set
Price Range 999.00 - 5999.00 USD ($)

Humidity Generation System Steam generator, automatic water supply
Door Seal Silicone Rubber Gasket
Shelves 2 (adjustable, stainless steel)
Observation Window Size 250 x 350 mm triple-glazed
Cooling Method Refrigeration compressor
Heater Type Nichrome wire heater
Sensor Type PT-100 Platinum resistance
Insulation Thickness 75 mm Polyurethane Foam
Ambient Temperature Operating Range +5C to +35C
Compliance Standards IEC, ASTM (select models)
Caster Type Heavy-duty swivel wheels with brakes
Cooling Medium R404A or R23 environmentally friendly refrigerant
Data Logging Built-in memory, downloadable via USB
Chamber Material (Interior/Exterior) Stainless Steel (SUS304) / Powder-Coated Mild Steel
Safety Features Overload protection, compressor delay protection, water shortage protection
Noise Level < 70 dB

Laboratory Temperature and Humidity Test Chamber Product Specifications

Automation Grade Automatic
Specimen Size Custom fitting inside chamber, up to 500x500x500 mm
Accuracy Temperature: 0.5C; Humidity: 2.5% RH
Application Environmental simulation, stability testing, research, quality control
Port Size 50 mm (Access port diameter)
Control Mode Programmable Microprocessor PID Controller
Test Width 600 mm (Chamber internal width)
Resolution Temperature: 0.1C; Humidity: 0.1% RH
Mounting Type Floor Standing
Features Over-temperature protection, automatic alarm, stainless steel inner chamber, viewing window, programmable cycles, wheels for mobility
Humidity 20%RH-98%RH
Test Speed Adjustable, typically 0.5-1.7C/min (heating/cooling)
Equipment Type Laboratory Temperature and Humidity Test Chamber
Number of Specimens 1-10 (varies by size)
Interface Type RS232/USB (optional)
Machine Weight Approx. 250-300 kg
Response Time Instantaneous readout, stabilization in 20 minutes
Max Height Internal 650 mm
Temperature 0C/-20C/-40C/-60C/-70C~+100C(+150C)
Display Type Digital LCD Touch Screen
Test Range Wide programmable temperature/humidity cycles
Capacity 150L (approximate chamber volume)
Operating Voltage 220V
Measuring Range Temperature: -40C to +150C; Humidity: 20%-98% RH
Power Supply 220V AC, 50Hz, Single Phase
Usage Testing material and product behavior under varied temperature and humidity
Frequency 50 Hz

Humidity Generation System Steam generator, automatic water supply
Door Seal Silicone Rubber Gasket
Shelves 2 (adjustable, stainless steel)
Observation Window Size 250 x 350 mm triple-glazed
Cooling Method Refrigeration compressor
Heater Type Nichrome wire heater
Sensor Type PT-100 Platinum resistance
Insulation Thickness 75 mm Polyurethane Foam
Ambient Temperature Operating Range +5C to +35C
Compliance Standards IEC, ASTM (select models)
Caster Type Heavy-duty swivel wheels with brakes
Cooling Medium R404A or R23 environmentally friendly refrigerant
Data Logging Built-in memory, downloadable via USB
Chamber Material (Interior/Exterior) Stainless Steel (SUS304) / Powder-Coated Mild Steel
Safety Features Overload protection, compressor delay protection, water shortage protection
Noise Level < 70 dB

Laboratory Temperature and Humidity Test Chamber Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

Laboratory Temperature and Humidity Test Chamber

Product description

This equipment can keep the temperature and humidity setup by users.Its' value can be alternative changed through the software.The device is application to test and confirm the property of

heat-resisting,cold-resisting,drying-resisting,humidity-resisting.,etc.It is widely used in the field of electron,electric equipment,communication,instrument,car,plastic,metal,food,chemical,building materials,medical,spaceflight.,etc.

Product features

(1)The outer case is made up of SUS304 steel plate.CNC processing molding,Beautiful design,Reacionless holder,easy operation

(2)Large LCD touching screen

(3)Adopt micro-computer temperature humidity controller.accuracy and reliability

(4)Large watching window;floodlight,of which can keep inside of chamber light;3 layers of vacuum glasses;can observe the status at any time

(5)Individual temperature limitation alarm system;automatically cut off when exceed temperature limitation;which can assure the safe testing

(6)Equipped with the testing hole with the diameter of 50mm at the both side of testing chamber.can be connected with outer power cable or signal cable

(7)Adopt high quality fixed PU running wheel in the bottle of machine

(8)New program temperature humidity chamber can save power more than 45% compared than the traditional type.can save responding time be around 50%.can deduct water consumption be around 80%

Main technical parameters

Model: DH-080

Interior dimensions: 40X50X40cm

Exterior dimenstions: 97X136X97cm

Internal volume(L): 80

Refrigerator: R404A R23 U.S.A HONEYWELL

Heater: Iron-chrome wire heater

Humidifier: Stainless steel sheathed heater

Water supply method: Water pump out system

High-Precision Environmental Simulation

Engineered to deliver accurate and repeatable temperature and humidity testing, this chamber is built for laboratories requiring high standards in environmental conditioning. The programmable PID controller enables tailored cycles, while the PT-100 platinum resistance sensors provide swift and reliable readings. With a measuring range of -40C to +150C and humidity from 20% to 98% RH, this chamber supports comprehensive research, product quality checks, and material stability evaluations.

Robust Construction, Enhanced Safety

This test chamber features a stainless steel (SUS304) inner chamber and a powder-coated mild steel exterior, delivering long-term durability and chemical resistance. It incorporates 75 mm polyurethane foam insulation for outstanding temperature stability. Multiple safety mechanisms-including overload, compressor delay, and water shortage protection-ensure safe operation, while heavy-duty casters offer mobility and stability during use.

User-Centric Features and Compliance Standards

Benefiting from an intuitive LCD touch screen for programming and operation, users can monitor and retrieve data via USB. The observation window offers clear triple-glazed viewing, while adjustable stainless steel shelves accommodate various specimen sizes. The chamber complies with international IEC and select ASTM standards (model dependent), making it suitable for global research and industrial applications.

FAQ's of Laboratory Temperature and Humidity Test Chamber:

Q: How does the temperature and humidity control system function in this test chamber?

A: The chamber employs a programmable microprocessor PID controller with PT-100 platinum sensors to maintain precise temperature (-40C to +150C) and humidity (20-98% RH) levels. Refrigerator compressors, steam generators, and a nichrome wire heater allow for accurate adjustments, while cycles can be set via an intuitive digital LCD touch screen.

Q: What materials are used in the construction of the chamber, and what benefits do they offer?

A: The interior is made of stainless steel (SUS304), ensuring corrosion resistance and easy cleaning. The exterior utilizes powder-coated mild steel for durability. Combined with 75 mm polyurethane foam insulation, these materials provide excellent thermal insulation, structural integrity, and longevity.

Q: When should safety features be utilized and how do they operate?

A: Safety features such as overload protection, compressor delay protection, and water shortage protection act automatically during operation to prevent system failure or damage. Over-temperature protection and automatic alarms alert users to abnormal conditions, ensuring safe, uninterrupted testing.

Q: Where can data logs be accessed and how are they retrieved from the chamber?

A: Test data is stored in the chamber's built-in memory and can be easily downloaded via USB or through the optional RS232 interface. This allows for straightforward transfer and analysis of test results on external computers or record-keeping systems.

Q: What is the process for specimen placement and observation during a test?

A: Specimens, up to a maximum size of 500x500x500 mm, are placed on the two adjustable stainless steel shelves inside the chamber. The triple-glazed observation window (250 x 350 mm) enables unobstructed monitoring of the specimen and test conditions without opening the door.

Q: What applications are best suited for this test chamber?

A: This chamber is ideal for environmental simulation, material stability testing, research experiments, and quality control in industries such as electronics, pharmaceuticals, and materials engineering. Its wide test range and programmable cycles accommodates varied testing protocols.

Q: How does the chamber ensure quick stabilization and accurate results?

A: The chamber boasts instantaneous readouts with full stabilization achieved within 20 minutes. Its high-resolution sensors (temperature: 0.1C, humidity: 0.1% RH) and accurate control (temperature: 0.5C, humidity: 2.5% RH) ensure consistent and reliable environmental conditions for rigorous laboratory testing.
