Product Description

AU-120RP Rubber and Plastic Density Testing Machine

Application:

rubber, plastic, tyre, shoe materials, macromolecule, composite materials, elastic materials, conveyer belt, transmission belt, soft synthetic leather,leather,new

materials researching laboratory.

This product is the new upgrade multi-function density measurement

instrument,which has been researched and developed for a long time;It has

the function of reading density value instantly,also the abrasion loss of relative volume,DIN,ARI,AKRON,expansion rate,change rate of quality and volume can be displayed.this machine has been applied widely and covered the whole rubber plastic industrial chain.

There are three different measuring mode:

density measuring M mode;

abrasion loss,expansion rate,density measurement D mode;

water absorption,quality and volume change rate measurement L mode.

Available Measuring Project and Standard:

1. Density of rubber,plastic and tyre;change rate of quality and volume;in accordance with ASTM D792,ASTM D297,GB/T533 standard.

2. Rubber expansion rate;in accordance with GB/T18173.

3. Volume abrasion loss DIN;in accordance with GB/T9867, DIN53516,I SO464.

4. AKRON abrasion loss;in accordance with GB/T1689.

5. Water absorption for other liquids.

6. solid density for other industries.

Measuring Resolution:

AU-120RP density resolution:0.0001g/cm3,weight resolution:0.001g,

abrasion loss resolution:0.01cm3

Features:

1.Density of any rubber plastic products with any shape can be measured.

2.Accuracy,simple operation,quick;meet laboratory operation standard and quick cycle testing requirement on site.

3.Function of 10 group data storage for density value and DIN volume abrasion loss.

4.Totally according to DIN53516 standard;function of calculating average value for multigroup data.

5.Either water or liquid can be used as medium.

6.Function of actual water temperature setting,measuring medium density setting,waterproof medium density setting,aerostatic buoyancy compensation setting.

7.Function of weight loss value setting,fixed weight loss value setting,density setting for reference rubber.

8.As for new materials researching and developing,the percentage content of main material for two mixed objects can be displayed.

9.Automatically judge if the samples is qualified or not by setting top and bottom limitation;alarm warning.

10.Function of automatic zero tracking,buzzer warning,and overload warning.

11.Adopt completed high capacity injection moulding PC water tank,which can resist wear,fall off,and corrosion.

12.Adopt completed special windproof and dustproof cover.which makes the structure more convenient and durable.

13.Including RS - 232C communication interface.it is convenient to connect PC with printer.DE-40 can be chose to print measuring data.

14.Gross weight/Size:4.5kg/length 42.5cm x width 17.5cm x height 32.5cm.

15.Power supply:AC 100V-240V 50HZ/60HZ Europe standard.

High-Precision Density Testing Made Easy

The AU-120RP automates the process of measuring the density of rubber and plastic samples, delivering accurate results every time. Its robust construction and intuitive controls offer dependable performance for various industrial settings. With its user-friendly features and compact design, the machine seamlessly fits into laboratory and production environments.


Versatile Operation for Indian Industry

Supporting a broad voltage range from 110V to 240V, the AU-120RP is perfect for diverse industrial settings across India. Whether you are a manufacturer, trader, supplier, distributor, or exporter, this density testing machine assures efficiency, consistency, and compliance with industry standards.
