Application:
Mineral,geological research,coal,archaeological researching,laboratory researching.,etc field.
Â
Function and Feature:
1. Easy operation,accuracy,reliability
2. All kinds of mineral can be tested instantly.no need to bind samples.automatically deduct the weight of suspension wire to zero.
3. Either water or liquid can be used as medium.
4. Adopt completed testing board and unobstructed without lifting lid design,more simpler operation,also makes the measuring result more reliable.
5. Adopt completed injection moulding transparent PC water tank(length 15.3cm x width 10.7cm x 9.3cm),which can resist wear,fall off,and corrosion.
6. Function of actual water temperature setting,measuring medium density setting,air buoyancy compensation setting,density top and bottom limitation setting.
7. Equiped special windproof dustproof cover,which makes the structure more convenient and durable.
8. Including RS - 232C communication interface.it is convenient to connect PC with printer.DE-40 can be chose to print measuring data.
9. Gross weight/Size:4.5kg/length 42.5cm x width 17.5cm x height 32.5cm
10. Power supply:AC 100V-240V 50HZ/60HZ Europe standard.
Technical Specification:
Â
Brand |
Quarrz |
||||||
Model |
AU-300R |
AU-600R |
AU-900R |
AU-1200R |
AU-120R |
AU-200R |
|
Weight |
Range |
0.005~300g |
0.005~600g |
0.01~900g |
0.01~1200g |
0.001~120g |
0.001~200g |
Standard deviation |
0.005g |
0.005g |
0.01g |
0.01g |
0.001g |
0.001g |
|
Density |
Readability |
0.001 g/cm3 |
0.0001 g/cm3 |
||||
Testing board |
ABS injection moulding |
Aluminum alloy die-casting moulding |
|||||
Range |
0.001~99.999g/cm3 |
0.0001~99.9999g/cm3 |
|||||
Result display |
True density,bulk density,effective porostiy,total porosity,opened pore porosity,closed pore porosity,moisture content can be measured. |
||||||
Measuring principle |
Archimedes principle buoyancy method |
||||||
Measuring time |
Around 5 ÃÂââÃÂìâÃÂà30 seconds |
||||||
 Opening lid method for testing board |
Rapid unobstructed without lifting lid design |
||||||
Water tank |
Completed injection moulding transparent PC water tank (size:length15.3 cmÃÂÃÂâÃÂÃÂwitdth10.7 cmÃÂÃÂâÃÂÃÂheight9.3cm) |
||||||
Parameter setting |
Actual water temperature setting,measuring medium density setting,saturation medium density setting,air buoyancy compensation setting,density top and bottom limitation setting |
||||||
Calibration method |
Single key calibration,automatically detection |
||||||
Standard accessories |
(1)host(2)water tank(3)testing board(4)tweezers(5)thermometers (6)weight(7)windproof dustproof cover(8) power transformer |
||||||
Data interface |
Standard RS-232 interface |
||||||
Optional accessoreis |
AU-40 printer,data connection wire |
||||||
Power supply |
Default as AC100V~240V 50HZ/60HZ  Europe standard; European Type;American Type;British Type;Australian Type |
||||||
Gross weight/size |
4.5kg/length42.5 cmÃÂÃÂâÃÂÃÂwidth17.5 cmÃÂÃÂâÃÂÃÂheight32.5cm |
