MIni Portable Gold Melting Induction Furnace Excellent Quality

Product Description

MIni Portable Gold Melting Induction Furnace Excellent Quality

Working Principle:

The power supply adopts the all-solid-state Siemens IGBT frequency conversion module technology. After the induction heating device outputs a strong variable frequency current, a strong magnetic field is generated through the induction coil. Under the action of the magnetic field, a vortex current is formed on the surface of the heated workpiece, thereby rapidly heating the workpiece.

Main Feature:

1.Fast heating: the fastest heating is less than 1 second, and the heating speed can be adjusted and controlled.

2.Energy saving and environmental protection: The thermal efficiency is over 95%, which is a perfect substitute for thyristor, gas, B, coke and electric furnace.

3.Machine safety is reliable: over-current, phase loss, water shortage, over voltage, short circuit, overheat protection, greatly improving the reliability of the equipment.

4.Small footprint: less than 1 square meter, light weight and easy to move.

5.The machine is easy to install and operate, just need to connect water and electricity.

6.It has electromagnetic stirring function to make the melt more uniform, which is beneficial to scumming, reducing impurities, making the melt or casting more bright without shrinkage and shrinkage.

7.Mainly for metals: platinum, palladium, rhodium, gold, silver, copper, steel, aluminum, activated carbon, gold ash, gold sand, electrolytic mud, gold and silver powder and other metals.

Specifiction:

1. Power supply input:220V/50/60Hz single phase
2. Output power:around 5KW
3. Melting metal type:gold,karat gold,silver,copper.,etc.
4. Maximum gold melting weight:1kg / 2kg gold
5. Melting time:3 - 5 minutes
6. Cooling water:Tap or cooling water circulation machine
7. Dimension(main host):49*24*48cm
8. Weight:20kg

Advanced Gold Melting Technology

Utilizing induction heating, this portable furnace ensures rapid and uniform melting of gold. Its automatic operation reduces manual intervention and improves safety during industrial processes. This state-of-the-art technology enables consistent results, meeting high-quality standards required in jewelry making and metal processing.


User-Friendly Design

This induction furnace boasts a compact and portable design, allowing for easy handling and transport between different work sites. Its simple interface and automatic functions make it accessible for operators of varying experience levels, boosting productivity and convenience for your melting applications.


Global Power Compatibility

Engineered to be compatible with Europe Standard AC 100V - 240V power supplies, this furnace can be used reliably across a wide range of locations. Its design caters to industries operating in Europe and other regions with similar voltage standards, ensuring seamless and hassle-free integration into your workflow.
