Electronic CNC Control Fully-Auto Vision Image Measuring Machine

4999.00 - 13999.00 USD ($)/Set

Get a Price/Quote

Product Details:

Measuring Range 200 mm 100 mm 150 mm (XYZ)
Port Size USB 2.0, Ethernet
Temperature 10C 30C
Response Time < 1 s
Application Precision measurement in electronics, hardware, plastics
Test Range 0 mm 200 mm
Power Supply AC 220V 10%, 50/60 Hz
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Electronic CNC Control Fully-Auto Vision Image Measuring Machine Price And Quantity

Price Range 4999.00 - 13999.00 USD ($)/Set
Minimum Order Quantity 1 Set

Safety Protections Emergency stop, overload protection
Language Support Multilingual interface including English and Chinese
Operating Environment No vibration, no corrosive gas
Imaging System High-resolution CCD camera with LED ring light
Calibration Method Fully electronic automatic calibration
Magnification Telecentric optical lens, 30X200X digital magnification
Working Table Material Granite base with precision linear guides
Data Output Supports reports in EXCEL and PDF formats
Image Capture Mode Automatic and manual
Software Support Intelligent measurement and analysis software

Electronic CNC Control Fully-Auto Vision Image Measuring Machine Product Specifications

Specimen Size Max 200 mm 100 mm
Test Stroke 200 mm (X-axis), 100 mm (Y-axis)
Usage Dimensional Inspection
Capacity Varies by fixture, up to 10 kg
Mounting Type Floor Stand
Test Width 300 mm
Power Supply AC 220V 10%, 50/60 Hz
Test Range 0 mm 200 mm
Temperature 10C 30C
Test Speed Configurable, up to 250 mm/s
Response Time < 1 s
Application Precision measurement in electronics, hardware, plastics
Port Size USB 2.0, Ethernet
Measuring Range 200 mm 100 mm 150 mm (XYZ)
Interface Type USB, Ethernet, RS232
Gas Pressure 0.5 0.8 MPa
Max Height 150 mm
Accuracy 2 m
Number of Specimens Single or Multiple
Display Type High-Resolution LCD Touchscreen
Automation Grade Fully Automatic
Equipment Type Fully-Auto Vision Image Measuring Machine
Machine Weight 450 kg
Control Mode Electronic CNC Control
Frequency 50/60 Hz
Resolution 0.001 mm
Operating Voltage AC 220V
Humidity 40% 90% RH
Features Auto focus, CNC control, Vision image processing

Safety Protections Emergency stop, overload protection
Language Support Multilingual interface including English and Chinese
Operating Environment No vibration, no corrosive gas
Imaging System High-resolution CCD camera with LED ring light
Calibration Method Fully electronic automatic calibration
Magnification Telecentric optical lens, 30X200X digital magnification
Working Table Material Granite base with precision linear guides
Data Output Supports reports in EXCEL and PDF formats
Image Capture Mode Automatic and manual
Software Support Intelligent measurement and analysis software

Electronic CNC Control Fully-Auto Vision Image Measuring Machine Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 15 Days
Main Domestic Market All India

Product Description

Electronic CNC Control Fully-Auto Vision Image Measuring Machine

Feature:

1.High precision automatic measuring,four axis CNC control.

2.High precision and high strength machine:00 marble base/upright column/worktable,high precision and good stability.

3.XYZ three axis imported precision linear guide rail/imported grinding level ball screw drive system.long service life,good stability.

4.High precision grating ruler 0.5um.

5.WM automatic zoom optical lens,automatic measurement,without zoom correction.

6.HD Japanese Sony CCD camera,high quality measuring screen.

7.Auto focus measurement,optical measuring altitude and flatness.and can be equipped with the British RENISHAW contact measuring head.

8.Program controlled three ring eight area surface light,LED profile light,coaxial light.Different products with different color light.

9.Equipped with control handle,easy to operate at any place.

10.Combined with imported software,3D measuring software is developed to improve the boundary resolution capability.

Specification:

Model: DH-CNC-4030A
X/Y axis stroke: 400MM*300MM
Z axis stroke: Effective space 245mm,focusing stroke 200mm,working distance 95mm
Metal countertop size: 550MM*450MM
Glass countertop size: 430MM*330MM
Optical ruler resolutioni X/Y/Z axis 0.0005MM (0.5UM)

Precision Meets Automation

This fully-automatic vision image measuring machine leverages an advanced CCD camera and telecentric lens to provide highly accurate non-contact measurements. With a measuring range of 200 x 100 x 150 mm (XYZ) and ultra-fine resolution, it is ideal for quality assurance tasks where exacting standards are paramount.

Seamless Integration and User-Friendly Operation

The machine is designed for convenience and versatility, offering USB, Ethernet, and RS232 connectivity. Its intelligent software supports multilingual interfaces and comprehensive data export, enhancing workflow compatibility in diverse industrial settings. The LCD touchscreen ensures intuitive operation for operators.

High Stability and Reliability

Built on a granite base with precision linear guides, the machine guarantees vibration-free, stable operation. Safety is prioritized through features such as emergency stop and overload protection, ensuring both operator and equipment are safeguarded during high-speed testing and automated calibration processes.

FAQ's of Electronic CNC Control Fully-Auto Vision Image Measuring Machine:

Q: How does the fully-auto vision image measuring machine ensure precise measurements?

A: The machine combines a high-resolution CCD camera, telecentric optical lens (30X-200X magnification), and precision-guided granite base. Its intelligent software and fully electronic automatic calibration further enhance measurement accuracy, achieving up to 2 m precision.

Q: What type of specimens can be measured, and what is the maximum allowable size and weight?

A: This machine accommodates single or multiple specimens with maximum dimensions of 200 mm 100 mm 150 mm and weights up to 10 kg, depending on the fixture used. It is suitable for parts from electronics, hardware, and plastics industries.

Q: When should I use the automatic versus the manual image capture mode?

A: Automatic image capture is ideal for routine batch measurements or process automation, while manual mode allows for targeted inspection or measurement of parts requiring special attention or adjustment by the operator.

Q: Where can the machine be installed for optimal performance?

A: Install the device in environments free from vibration and corrosive gases, maintaining temperatures between 10C and 30C, and relative humidity from 40% to 90% RH. A stable, level floor is necessary for the granite base and CNC control system.

Q: What is the data output process, and which formats are supported?

A: Measurement data can be automatically exported to EXCEL or PDF reports via the machine's intelligent software, using USB or Ethernet interfaces for convenient integration with existing digital workflows.

Q: How does the fully electronic automatic calibration function benefit users?

A: Fully electronic automatic calibration eliminates manual setup, streamlines routine maintenance, and ensures consistent measurement accuracy, reducing downtime and human error in high-precision inspection tasks.

Q: What safety measures are incorporated in this machine?

A: Key safety features include an emergency stop button and overload protection mechanism, which collectively prevent mishaps and safeguard the machine during operation, contributing to a secure working environment.
