C Series Horizontal Vertical Electromagnetic Vibration Table Shaker

1503.00 - 7299.00 USD ($)/Set

Get a Price/Quote

Product Details:

Temperature 0C~45C
Max Height About 880 mm
Measuring Range 0~5 mm (displacement)
Port Size Standard M12
Frequency 1~200 Hz
Mounting Type Tabletop
Equipment Type Electromagnetic Vibration Table Shaker
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

C Series Horizontal Vertical Electromagnetic Vibration Table Shaker Price And Quantity

Price Range 1503.00 - 7299.00 USD ($)/Set
Minimum Order Quantity 1 Set

Shaker Type Electromagnetic with table structure
Safety Features Overload, overcurrent and overheat protections
Vibration Waveform Sine, Square, Triangular (programmable)
Dimension 800 x 600 x 880 mm (L x W x H)
Table Material High-strength aluminum alloy
Cooling Method Air cooled
Max Acceleration 20 g
Service Support On-site installation and remote diagnostics available
Noise Level <65 dB
Vibration Direction Horizontal and Vertical modes

C Series Horizontal Vertical Electromagnetic Vibration Table Shaker Product Specifications

Features Horizontal & Vertical testing, programmable, compact structure
Number of Specimens Multiple (as per table size)
Operating Voltage 220 V
Humidity 85% RH (non-condensing)
Resolution 0.01 mm
Test Range Horizontal & Vertical vibration
Interface Type RS232 (optional)
Application Vibration testing of components, electronics, packaging and other materials
Usage Laboratory and Quality Control
Specimen Size Up to 400 x 400 mm
Response Time <1 s
Display Type Digital LCD
Automation Grade Semi-automatic
Accuracy 0.5% F.S.
Mounting Type Tabletop
Test Speed 1~200 Hz (adjustable)
Equipment Type Electromagnetic Vibration Table Shaker
Hardness N/A (non-applicable)
Test Width 500 mm
Control Mode Digital & Manual
Power Supply AC 220V, 50Hz
Machine Weight Approx. 150 kg
Max Height About 880 mm
Temperature 0C~45C
Capacity 60 kg
Frequency 1~200 Hz
Port Size Standard M12
Test Stroke 0~5 mm (adjustable)
Measuring Range 0~5 mm (displacement)

Shaker Type Electromagnetic with table structure
Safety Features Overload, overcurrent and overheat protections
Vibration Waveform Sine, Square, Triangular (programmable)
Dimension 800 x 600 x 880 mm (L x W x H)
Table Material High-strength aluminum alloy
Cooling Method Air cooled
Max Acceleration 20 g
Service Support On-site installation and remote diagnostics available
Noise Level <65 dB
Vibration Direction Horizontal and Vertical modes

C Series Horizontal Vertical Electromagnetic Vibration Table Shaker Trade Information

FOB Port Shenzhen
Supply Ability 300 Set Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

C Series Electromagnetic Sweeping Vibration Table 1-600HZ (Vertical + Horizontal + Front and Rear) DH-VT-500-C3

Application:

Electromagnetic vibration table are widely used in industries such as defense, aviation, communications, electronics, automobiles, home appliances, and others. This type of equipment is used to find early faults, simulate actual working conditions and structural strength tests. The product has a wide range of applications, wide application areas, and significant and reliable test results. Sine wave, frequency modulation, frequency sweep, programmable, frequency doubling, logarithmic, time control.

Features:

1. Using the most advanced and simple operation technology, fixed frequency, sweep frequency is convenient to switch at any time

2. With time timing, countdown display function

3. Touch controller, simple and convenient operation, solve the shortcomings of inconvenience of digital display operation

4. The control parameters are displayed synchronously in real time without manual intervention.

5. The base of the machine adopts vibration isolation device, which is easy to install and runs smoothly, without the need to install anchor fixing screws

6. Embedded amplitude prediction program and easy amplitude modulation

7. Four-point synchronous vibration, uniform table vibration

8. Stepless adjustment of amplitude, fixed frequency and frequency sweep operation functions adapt to various test requirements in different industries

9. Add anti-interference circuit to solve the interference of the control circuit due to strong electromagnetic field

10.Curve display function, can view the frequency waveform changes at any time

Specification:

Test load:60KG

Vibration direction: Vertical + horizontal + front and back (manual switching)

Table size (mm): 500*500

Amplitude (P-P): 0-5mm (random, change with frequency, adjustable)

Frequency sweep: 1-600HZ can be set arbitrarily (true standard back and forth frequency sweep)

Maximum acceleration: 10g

Indicator function: FM, frequency sweep, time

Accuracy: Frequency can be displayed to 0.1Hz, precision 0.1Hz

Multiplier work (0.1Hz): 8-segment multiplier increase 1.Low to high frequency 2.High to low frequency 3.Low to high and then low frequency/recyclable

Logarithmic work (0.1Hz):1.Down to up frequency 2. Up to down frequency 3. Down to up then down frequency-3 modes logarithmic/recyclable

Vibration waveform:Sine wave

Time control:Time can be set

Power:1.2KW

Simultaneous Horizontal and Vertical Vibration Testing

Designed for comprehensive vibration assessments, the C Series shaker enables testing in both horizontal and vertical orientations. Its digital and manual control modes offer flexibility, while programmable sine, square, and triangular waveforms expand testing versatility. The adjustable test stroke (0-5 mm) and max acceleration of 20 g support a broad range of application requirements.

High-Strength Construction and Precise Performance

Built with a high-strength aluminum alloy table, the shaker ensures outstanding durability and stability during operation. Capable of safely holding specimens up to 60 kg, it delivers consistent results with a measuring accuracy of 0.5% F.S. and excellent resolution (0.01 mm). The compact tabletop design facilitates easy integration into laboratory setups.

Safety and Support for Reliable Operation

The shaker is equipped with comprehensive safety measures, including overload, overcurrent, and overheat protections, safeguarding both equipment and users during intense test cycles. Installation support and remote diagnostics are available, ensuring seamless setup and ongoing maintenance. It's designed to operate quietly (<65 dB) and efficiently under varied temperature (0C~45C) and humidity (85% RH) conditions.

FAQ's of C Series Horizontal Vertical Electromagnetic Vibration Table Shaker:

Q: How do I operate the C Series Electromagnetic Vibration Table Shaker?

A: The shaker can be controlled via both digital LCD and manual interfaces. After securely mounting your specimen on the high-strength aluminum table, select your desired vibration mode (horizontal or vertical), adjust the frequency (1-200 Hz), test stroke, and waveform through the programmable controls. Then, start the test and monitor performance through the digital display.

Q: What types of specimens and applications is this shaker suitable for?

A: This vibration table shaker is designed for components, electronics, packaging, and other materials that require durability and vibration resistance testing. It accommodates specimens up to 400 x 400 mm in size and 60 kg in weight, making it ideal for laboratory and quality control environments.

Q: When and where should this equipment be used for optimal performance?

A: The shaker is best used in clean, controlled environments such as laboratories, R&D centers, or production quality control rooms. It operates optimally at temperatures between 0C and 45C and at humidity levels 85% RH (non-condensing). Its compact tabletop design allows for easy placement on standard laboratory benches.

Q: What safety features are included to protect users and equipment?

A: Equipped with overload, overcurrent, and overheat protections, the shaker ensures safe operation throughout testing. These features automatically intervene to prevent damage to the machine or test specimens during abnormal conditions, alerting the user via the LCD display.

Q: How can I benefit from its programmable vibration waveforms?

A: The shaker can generate sine, square, and triangular waveforms, all programmable to suit specific testing scenarios. This flexibility allows for comprehensive vibration simulations and targeted stress tests, helping users meet various testing standards and application requirements.

Q: What support is available for installation and troubleshooting?

A: On-site installation and remote diagnostics services are offered. Professional technicians can assist with initial setup, while ongoing remote support and diagnostics ensure the equipment remains in optimal condition for reliable, long-term use.
