Plastics Horizontal/Vertical Combustion Tester

Plastics Horizontal/Vertical Combustion Tester

Name: Plastics Horizontal/Vertical Combustion Tester
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 1740.0 USD
Availability: InStock

1740.0 USD ($)

Get a Price/Quote

Product Details:

Humidity Relative Humidity: 45-75%
Features Fully enclosed testing chamber, exhaust vent, flame application jig, adjustable flow meters, gas pressure regulators
Power Supply AC 220V, 50Hz
Hardness Not applicable (for soft and hard plastics alike)
Application Flammability test for plastic materials in horizontal and vertical positions
Test Range UL 94 horizontal and vertical burning test for plastics
Frequency 50 Hz
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Plastics Horizontal/Vertical Combustion Tester Price And Quantity

Price 1740.0 USD ($)
Minimum Order Quantity 1

Plastics Horizontal/Vertical Combustion Tester Product Specifications

Usage Material quality control, laboratory and industrial specifications
Specimen Size 125 mm 13 mm thickness (0.4-13 mm recommended)
Test Stroke Horizontal/vertical specimen movement as per UL94
Accuracy 1% for timing, 2 mm for specimen size
Mounting Type Bench-top/portable
Test Width Specimen holder width: 75 mm
Equipment Type Plastic Combustion Tester
Measuring Range 0-999 seconds (digital timing system)
Resolution 0.1 second (digital timer)
Machine Weight ~60 kg
Port Size Standard outlet and inlet ports for gas supply
Max Height Chamber height: 400 mm
Temperature Room temperature, test can be performed from 15C~35C
Number of Specimens 1 at a time
Interface Type Touch panel/Manual buttons
Capacity One specimen per cycle
Automation Grade Semi-automatic
Operating Voltage 220V AC
Control Mode Touch screen digital control
Features Fully enclosed testing chamber, exhaust vent, flame application jig, adjustable flow meters, gas pressure regulators
Humidity Relative Humidity: 45-75%
Power Supply AC 220V, 50Hz
Hardness Not applicable (for soft and hard plastics alike)
Application Flammability test for plastic materials in horizontal and vertical positions
Test Range UL 94 horizontal and vertical burning test for plastics
Test Speed Adjustable (automatic/manual mode)
Response Time Immediate (electronic control)
Gas Pressure 10~50 kPa (adjustable)
Frequency 50 Hz
Display Type LCD digital screen

Flame Height Adjustment 20 mm and 40 mm selectable
Burner Angle Adjustable (0/20/45 for different test standards)
Exhaust System Built-in manual vent/automatic exhaust optional
Lighting Built-in observation light
Test Standards Supported UL94, IEC60695-11-10, ISO1210, GB/T2408
Gas Type Methane or natural gas (standardized for UL94)
Data Output USB/RS232 optional
Test Chamber Material Anti-corrosive, powder-coated steel
Noise Level 50 dB during operation
Timer Type Multifunctional, digital with memory
Safety Features Emergency stop, overheat protection, sealed test chamber
Ignition Method Electronic automatic igniter
Observation Window Transparent, heat-resistant glass
Mobility Equipped with lockable caster wheels

Product Description

The Plastics Horizontal/Vertical Combustion Tester garners favorable reviews for its exceptional performance in flammability testing of a diverse range of plastic materials. This venerable, well-decorated piece of equipment features a spectacular design, with a selectable flame height (20mm/40mm) and adjustable burner angles for diverse standards compliance. The fully enclosed, corrosion-resistant steel test chamber is engineered for safety and reliability, boasting advanced features such as touch screen controls, emergency stop, and automatic ignition. Data export options, premium observation windows, and optional exhaust systems set this tester apart, making it a special, highly sought-after solution-available for a limited time, with offers ending soon.

Versatile Application Across Industries and Laboratories

Designed for material quality control, research laboratories, and industrial settings, the Plastics Horizontal/Vertical Combustion Tester excels at flammability testing in both horizontal and vertical configurations. Its application area spans standards-based certification, educational research, and manufacturing quality assurance processes. This robust instrument is essential for polymer manufacturers, testing labs, and compliance teams striving to meet stringent regulatory requirements and enhance safety protocols.

Widespread Market Acceptance and Competitive Payment Options

Rated as a premium solution in the domestic market, this combustion tester is renowned for swift quotations and competitive pricing. It comes fully certified to carry out UL94 and ISO1210 procedures, ensuring high reliability and acceptance for export or local distribution. Favorable payment terms accommodate government, research, and enterprise procurement, reflecting the manufacturer's commitment to excellence and customer-focused service.

FAQ's of Plastics Horizontal/Vertical Combustion Tester:

Q: How does the Plastics Horizontal/Vertical Combustion Tester benefit quality control processes?

A: This tester provides precise, repeatable measurements of plastic flammability, helping quality control teams ensure material compliance with industry safety standards such as UL94, thereby reducing product liability issues and improving reliability.

Q: What types of plastic specimens can be tested with this equipment?

A: The tester accommodates a wide variety of plastic materials, both soft and hard, provided they meet the recommended specimen size of 125mm 13mm with a thickness of 0.4-13mm.

Q: Where is the ideal site of application for this combustion tester?

A: It is ideal for quality assurance laboratories, material research departments, educational institutions, and industrial production sites requiring standard-compliant flammability testing.

Q: When should the Plastics Combustion Tester be used during product development?

A: It is best used during prototyping, material sourcing, or pre-market approval phases to verify the flammability rating and compliance of new or modified plastic components.

Q: What is the process for adjusting burner angles and flame heights during a test?

A: Burner angles can be set to 0, 20, or 45, and flame height is selectable between 20mm and 40mm. Adjustments are made via touch panel controls, ensuring the test meets different international standards.

Q: How is test data recorded and exported from the combustion tester?

A: Test data is digitally logged and can be exported through USB or RS232 interface, facilitating efficient documentation and analysis for quality records or regulatory submissions.
