Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing

Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing

Name: Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 751.0 USD
Availability: InStock

751.0 USD ($)/Unit

Get a Price/Quote

Product Details:

Temperature Selectable up to 200C (halogen heating)
Port Size Standard sample pan
Application Moisture determination in food, pharmaceuticals, chemicals, agriculture, etc.
Number of Specimens Single specimen per test
Features Halogen heating, rapid drying, digital controls, automatic tare, easy calibration
Equipment Type Halogen Heating Moisture Analyzer
Humidity Not Applicable for measurement (measures sample humidity)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing Price And Quantity

Price 751.0 USD ($)/Unit
Minimum Order Quantity 1 Unit

Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing Product Specifications

Specimen Size Typically up to 110g
Automation Grade Semi-automatic
Response Time Approx. 2-5 minutes (sample dependent)
Test Range 0.01g to 110g
Machine Weight 3.5 kg
Display Type Large LCD display
Power Supply 220V AC, 50Hz
Interface Type RS232 (optional for data transfer)
Control Mode Digital control panel
Resolution 0.001g/0.01%
Frequency 50Hz
Port Size Standard sample pan
Application Moisture determination in food, pharmaceuticals, chemicals, agriculture, etc.
Temperature Selectable up to 200C (halogen heating)
Number of Specimens Single specimen per test
Equipment Type Halogen Heating Moisture Analyzer
Features Halogen heating, rapid drying, digital controls, automatic tare, easy calibration
Humidity Not Applicable for measurement (measures sample humidity)
Usage Fast and accurate moisture testing
Mounting Type Desktop/Laboratory bench
Capacity 110g maximum sample load
Operating Voltage 220V AC
Accuracy 0.01g or 0.01% moisture
Test Speed Fast - results within minutes
Measuring Range 0.01g to 110g

Data Storage Yes (last few measurements)
Pan Diameter 90 mm
Heating Source Halogen Lamp
Calibration External weight calibration
Housing Material ABS Plastic
Sample Tray Material Stainless Steel
Safety Feature Overheating protection and warning alert
Sample Display Moisture %, Solid %, Weight, Dry Weight
Languages Supported English by default
End Point Modes Auto, Timed, Manual
Ambient Operating Conditions 10C to 40C

Product Description

Introduction:

The apparatus is the updated one that can test moisture content quick and accurately.It's annular halogen light could have sample heated evenly.easy operation and precise measurement.when weight is measured,sample is quick dried by heating through halogen light.this machine measure continuously and display missing moisture content % immediately.After drying process is done,final measured moisture content value is locked.Compared with international oven heating method,halogen heating would have sample heated evenly in high temperature.the surface of sample would not be damaged easily.It's testing result has the good consistency with international oven heating method.Plus,it is more efficient.In general,it just take few minutes to finish measuring.This machine can display value respectively:moisture value,specimen initial value,final value,measuring time,determination time,temperature initial time,final time.,etc data.In addition,it has the function of connection with computer and printer.

Application:

This instrument has been widely used in all fields which need to measure moisture quickly.such as PP,PE,PVC,PS,PA,PC,PET,PPS,plastic auxiliaries,plastic raw material.,etc.other than that,it would satisfy the measuring requirement for solid,granule,powder,colloid and liquid.

In accordance with the thermogravimetric principle.

Features:

1) High-precision precision balance base

2) Long-life 510W halogen heating source

3) Widely used, good temperature control performance, high measurement accuracy, durable

4) Can display moisture value, solid content value and other results

5) Multiple measurement modes such as automatic mode and timing mode

6) LCD screen display;

7) Has the function of connecting to computers and printers. (Optional accessories)

Technical Parameters:

Model	DH-60
Measuring Range	110g
Weighing accuracy	0.001g
Moisture readability	0.01%
Repeatability	0.05% (5g sample) 0.02% (10g sample)
Moisture value range	0.01% to 100%
Temperature range	60C200CInterval 1C
Heating unit	Halogen heating
Display results	%Moisture content, % solids, weight
Display screen	LCD display
Output	RS232
Power supply	240 VAC 50/60 Hz
Operation temperature	10C to 40C
Sample tray size	90 mm
Accessories	10 sample trays, one pair of tweezers, one calibration weight, one power cord, one instruction manual
Optional	RS-232C connection cable, dedicated printer equipment
Gross dimension(WxHxD)	460 x 370 x 289 mm
Gross weight	7.79kg

Accelerated and Accurate Moisture Testing

Experience rapid and accurate moisture analysis with the advanced halogen heating system, which enables precise measurements within minutes. Designed for laboratory and industrial environments, the analyzer ensures minimal waiting, maximum accuracy, and swift decision-making for quality control and production processes.

User-Centric Design and Digital Controls

Equipped with a large LCD display, intuitive digital control panel, and easy calibration features, the Halogen Heating Moisture Analyzer simplifies routine moisture testing. The automatic tare, selectable temperature settings up to 200C, and multiple languages (English default) enhance user convenience and adaptability for professionals.

Built-In Safety and Reliability

With the integration of overheating protection and an alert system, operators are kept safe from excessive temperatures during operation. The durable ABS plastic housing and stainless steel sample tray add longevity, while data storage for recent measurements aids in tracking and documentation.

FAQ's of Halogen Heating Moisture Analyzer for Fast and Accurate Moisture Testing:

Q: How does the Halogen Heating Moisture Analyzer determine moisture content quickly?

A: The analyzer rapidly measures moisture by using a halogen lamp to heat the sample, causing moisture evaporation. The loss in weight is tracked and displayed as moisture percentage, solid percentage, weight, and dry weight, typically providing results in 2 to 5 minutes depending on the sample.

Q: What types of samples and applications are suitable for this moisture analyzer?

A: This instrument is ideal for testing solid and semi-solid samples in industries such as food, pharmaceuticals, chemicals, and agriculture. Its 110g capacity and 0.01g/0.01% accuracy make it versatile for various laboratory and industrial quality control applications.

Q: When should I calibrate the moisture analyzer, and how is it performed?

A: Calibration is recommended regularly or after moving the device to a new location to ensure continued accuracy. It is performed using external calibration weights, following prompts on the digital control panel for straightforward calibration.

Q: Where can this analyzer be installed or used most effectively?

A: The analyzer is designed for desktop or laboratory bench installation in controlled environments between 10C and 40C, making it suitable for research labs, production facilities, and quality control departments.

Q: What safety features does the analyzer include during operation?

A: It features overheating protection and a warning alert system to prevent unsafe operation conditions. The robust ABS plastic housing and stainless steel tray also contribute to safe, long-lasting use.

Q: How does data storage and transfer work on this moisture analyzer?

A: The device can store the most recent measurement data, ensuring easy access for review. An optional RS232 interface supports data transfer for documentation or integration with lab information systems.

Q: What are the benefits of using a halogen heating system in moisture analysis?

A: Halogen heating enables faster drying and more homogeneous heat distribution compared to other methods, resulting in quicker, more consistent, and reliable moisture measurements for laboratory and production settings.
