DH-TA-02 Taber Linear Abrasion Testing Machine
1148.00 INR/Unit
Product Details:
- Operating Voltage 220V
- Specimen Size Maximum 60 mm width, 300 mm length
- Interface Type Digital, touch interface
- Test Range 0~99999 cycles
- Hardness Not directly applicable (test samples may vary)
- Port Size Standard specimen clamp, customizable
- Temperature 10C~40C
- Click to view more
X
DH-TA-02 Taber Linear Abrasion Testing Machine Price And Quantity
- 1 Unit
- 1148.00 INR/Unit
DH-TA-02 Taber Linear Abrasion Testing Machine Product Specifications
- 1 cycle
- Programmable stroke & speed, digital cycle display, emergency stop
- Instantaneous
- Abrasion resistance testing of coatings, plastics, textiles, leather, rubber, etc.
- 20%~80% RH
- Benchtop
- Varies by test arm weight attachment (typically 250-1000g)
- Taber Linear Abrasion Testing Machine
- 0-99999 cycles
- 50Hz
- 1 cycle
- Touch screen digital display
- Semi-automatic
- AC 220V, 50Hz
- Linear abrasion/wear testing
- 10C~40C
- 20~300 mm adjustable
- Standard specimen clamp, customizable
- 10~60 mm
- 32 kg
- Not directly applicable (test samples may vary)
- 1~75 cycles/min adjustable
- 0~99999 cycles
- Not specified (depends on arm clearance)
- 0.4~0.7 MPa (if applicable for pneumatic models)
- 1 (per test run)
- Maximum 60 mm width, 300 mm length
- Touch screen controller
- 220V
- Digital, touch interface
- Specimen holders, abrasive pads, user manual
- High, with precise digital controller
- 250g, 500g, 750g, 1000g configurable weights
- 120W
- Automatic stop at preset cycles
- Multi-language touch panel
- 420 x 460 x 300 mm (LxWxH)
- Stainless steel
- Manual via scale
- Hard metal alloy
Product Description
Overview:
The linear abrasion tester is used to evaluate the abrasion resistance, scratch resistance (single or multiple scratches) and color transferability (usually resistance to friction discoloration or rubbing fastness) and so on. Both dry abrasion test and wet abrasion test can be performed.
Application:
It can test samples of any size or shape. It is ideal for the abrasion test of products with contoured surface and polished surface characteristics (such as: computer mouse and other computer or IT product plastic surface paint abrasion resistance test), It is applied to universal plastics, auto parts, rubber, leather and textiles, electroplating, freely disassembled components, paints, printed patterns and other products.
Standards:
ASTM D3884,ASTM D1175,ASTM D1044,ASTM D4060,TAPPI T476,ISO 9352,ISO 5470-1,JIS K7204,JIS A1453,JIS K6902,JIS L1096,JIS K6964,JIS L1096,JIS K6964,DIN 52347,DIN 53109,DIN 53754,DIN 53799,conforms to CE standards
Features:
1. Parameters such as moving distance, rotation speed, number of revolutions, and load can be set.
2. A variety of different wear media and accessories can be selected. (Can choose sample fixing table and other optional accessories to do the damage test, alcohol resistance test, coin scratch resistance test, etc.)
To ensure the stability and accuracy of the test: The general grinding head is similar in size and shape to the eraser head at the end of a pencil, and is made of high-quality abrasion materials. Can ensure the stability of the test.
Standard configuration:
Including 5750 main machine, 3 pcs of 250G disc-shaped weights.
1.5 optional moving distances: 0.5, 1, 2, 3 and 4; special moving distances can be customized.
2). The number of test revolutions can be set, up to 999,999 revolutions (note that the grinding head rubber may need to be replaced during this period).
3).Adjustable moving speed of 260 reciprocating/min. Among them, the six speeds of 2, 15, 30, 40 and 60 round trips/min are TABER standard measurements. The higher moving speed of this machine is 60 round trips/min.
4). The load can be selected.
Standard load range: 350g measuring rod, 3 pcs of 250g weights is randomly equipped.
(Various weights can also be customized)
Advanced Linear Abrasion Testing
The DH-TA-02 provides meticulous abrasion and wear testing across a variety of materials including coatings, plastics, textiles, and rubbers. With its configurable arm loads and adjustable stroke, it allows precise customization to meet distinct sample requirements. The automatic digital controller and multi-language touch panel interface facilitate seamless test programming and monitoring, ensuring repeatable, accurate results every time.
User-Friendly, Precise Control
The integrated touch screen digital display offers an intuitive test set-up and instant feedback. Stroke length, speed, and cycle count are programmable, while the machine automatically halts at preset cycles thanks to its end-of-stroke sensor. Calibration and sample mounting are straightforward, and provided specimen holders plus abrasive pads allow for quick test preparation.
Versatility and Safety at Its Core
Whether you're a manufacturer or a quality control lab, the DH-TA-02 is engineered for both flexibility and safety. Its bench-top design, broad environmental range, and customizable specimen clamps make it suitable for multiple application scenarios. The semi-automatic operation with emergency stop function ensures operator safety throughout prolonged use.
FAQ's of DH-TA-02 Taber Linear Abrasion Testing Machine:
Q: How is the abrasion test performed with the DH-TA-02 Taber Linear Abrasion Testing Machine?
A: Tests are conducted by securely mounting the specimen onto the work table, selecting the desired load weight (250g-1000g), adjusting the arm stroke manually, and setting parameters via the touch screen. The machine then moves the test arm linearly across the sample, simulating wear, to assess abrasion resistance over programmable cycles.Q: What types of materials can be tested using this abrasion machine?
A: The DH-TA-02 is suitable for evaluating coatings, plastics, textiles, leather, rubber, and similar flat or slightly flexible materials. Its adjustable fixtures and arm loads make it adaptable to a broad range of sample specifications.Q: When should I use the programmable stroke and speed features?
A: Programmable stroke (20-300 mm) and speed (1-75 cycles/min) allow you to replicate various real-world wear conditions. Utilize these features when testing samples that require simulation of specific linear abrasion distances or cycle speeds, ensuring test protocols are relevant to actual product use.Q: Where is this testing machine typically installed and operated?
A: The DH-TA-02 is a benchtop device designed for use in laboratories, quality assurance departments, and R&D facilities in industrial or academic settings. Its standard footprint and digital controls make it suitable for both production line testing and research scenarios.Q: What is the process for setting up a test sample?
A: To set up a test, position your prepared specimen (max 60 mm width, 300 mm length) onto the stainless steel table using the provided specimen holders. Attach the appropriate arm load, adjust the test stroke manually, and use the touch screen to enter speed, cycles, and language preferences before starting the abrasion test.Q: How does the DH-TA-02 ensure repeatability and accuracy during testing?
A: Equipped with a precise digital controller and a high-resolution cycle counter (1 cycle accuracy), the machine delivers highly repeatable results. The automatic end-of-stroke sensor stops the machine at preset cycles, minimizing human error and ensuring consistent test protocols.Q: What are the main benefits of using this machine for abrasion testing?
A: Key benefits include precise digital control, customizable test parameters, multi-language support, robust construction, automatic cycle counting, and broad material compatibility. These features allow operators to perform reliable, repeatable abrasion tests, enhancing product quality and compliance with industry standards.Tell us about your requirement
