DH-339 Wear Resistance Testing Machine

Name: DH-339 Wear Resistance Testing Machine
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 457.00 INR
Availability: InStock

457.00 INR/Unit

Get a Price/Quote

Product Details:

Display Type Digital LED display
Humidity 5%~85% RH (operating)
Power Supply AC 220V 50Hz
Measuring Range 0~999,999 cycles
Specimen Size 50 x 50 mm
Resolution 1 cycle
Accuracy 1 cycle
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

DH-339 Wear Resistance Testing Machine Price And Quantity

Price 457.00 INR/Unit
Minimum Order Quantity 1 Unit

DH-339 Wear Resistance Testing Machine Product Specifications

Capacity Standard dual-station
Test Speed 5~60 cycles/min adjustable
Display Type Digital LED display
Power Supply AC 220V 50Hz
Measuring Range 0~999,999 cycles
Humidity 5%~85% RH (operating)
Specimen Size 50 x 50 mm
Resolution 1 cycle
Test Stroke 20~120 mm adjustable
Accuracy 1 cycle
Usage Material laboratory, quality control
Gas Pressure No gas supply required
Number of Specimens 2 positions
Response Time Immediate (digital control)
Application Textile, leather, coating and other material wear resistance testing
Features High precision, durable, easy to operate, dual station
Port Size Standard specimen slot
Temperature 10C~40C (operating)
Frequency 50Hz
Max Height Standard test arm clearance 80 mm
Control Mode Digital control panel
Machine Weight Approx. 35 kg
Equipment Type Wear Resistance Testing Machine
Operating Voltage 220V
Test Range Wear and abrasion resistance
Automation Grade Semi-automatic
Test Width 50 mm
Mounting Type Bench-top
Interface Type Button control panel
Hardness Test platform stainless steel, hardness >HRC45

Power Consumption <200W
Safety Protection Emergency stop switch included
Housing Material Stainless steel and aluminum alloy
Noise Level <70 dB
Clamping Method Adjustable mechanical clamps
Test Load Up to 500g (with optional weights)

Product Description

Technical parameters:

Material of the main machine: stainless steel

Friction frequency: stepless adjustable speed frequency

Friction counter: adjustable 0-99999999 times

Friction speed: 0 - 100 times (adjustable)

Friction distance: 0mm - 50mm freely adjustable

The test rod can be adjusted up and down to the required distance

Dimensions: 63x45x37 (LxWxH) cm

Standard accessories:

2 test rods of 60g

Weights 500g, 200g, 100g, 50g, 20g, 10g each

A set of hexagonal wrenches

One power cord

High-Precision Wear Resistance Testing

The DH-339 Wear Resistance Testing Machine offers exact results with a resolution and accuracy of 1 cycle. Its digital control panel and immediate response time allow users to monitor tests precisely and adjust parameters on the fly, ensuring reliable data for comprehensive material comparison.

Durable and Safe Construction

Engineered using stainless steel and aluminum alloy, the DH-339 ensures long-lasting performance and strong resistance to harsh testing environments. The integrated emergency stop switch adds an essential layer of safety for operators, meeting rigorous laboratory safety requirements.

Adaptable and User-Friendly Operation

With adjustable clamp mechanisms, dual testing stations, and semi-automatic operation, the DH-339 is designed for flexible sample testing. The machine supports up to 500g test loads and can adjust speed, stroke, and clamping force, making it suitable for diverse applications in textile, leather, and coating industries.

FAQ's of DH-339 Wear Resistance Testing Machine:

Q: How does the DH-339 Wear Resistance Testing Machine operate?

A: The DH-339 uses an adjustable mechanical clamp system to secure specimens. You can set the test speed (5-60 cycles/min), test stroke (20-120 mm), and test load (up to 500g) on its digital control panel. The machine then measures the wear resistance over a customizable number of cycles.

Q: What materials can be tested with this machine?

A: The DH-339 is suitable for testing textiles, leather, coatings, and other materials that require evaluation of their abrasion and wear resistance. The standard 50 x 50 mm specimen size ensures compatibility with a variety of material samples.

Q: When should I use the emergency stop feature?

A: The emergency stop switch should be used immediately if you encounter any operational irregularity or safety concern during testing. This halts all machine activity instantly to protect both the operator and specimens.

Q: Where is the DH-339 most commonly used?

A: This machine is ideal for material laboratories, research facilities, and industrial quality control departments, particularly those focusing on textiles, coatings, leather, and related products.

Q: What is the typical process of running a wear resistance test on the DH-339?

A: To conduct a test, securely position your specimens using the adjustable clamps, set your desired test parameters (load, speed, stroke) through the digital control panel, and initiate testing. The device records cycles digitally, with immediate results available via the LED display.

Q: What are the main benefits of using the DH-339 for wear resistance testing?

A: The DH-339 provides dual-station testing for greater throughput, high-precision results, robust construction for durability, and a user-friendly interface. Its adjustable parameters allow for comprehensive and repeatable testing across various materials, enhancing your quality control processes.
