Automatic Image Measuring Instrument

Name: Automatic Image Measuring Instrument
Brand: Guangdong Hongtuo Instrument Technology Co.,Ltd .
Price: 10499.0 USD
Availability: InStock

10499.0 USD ($)

Get a Price/Quote

Product Details:

Specimen Size Max 600 x 500 mm Millimeter (mm)
Test Range 600 mm x 500 mm x 200 mm
Power Supply AC 220V / 50Hz
Display Type Computer-based Digital Display
Features High Accuracy, Motorized Stage, Auto Focus, CNC Control
Accuracy 2.8 + L/200 m %
Max Height 200 mm (Z axis)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Automatic Image Measuring Instrument Price And Quantity

Price 10499.0 USD ($)
Minimum Order Quantity 1

Automatic Image Measuring Instrument Product Specifications

Number of Specimens Single or Multiple
Mounting Type Floor Standing
Automation Grade Automatic
Operating Voltage 220 V AC Volt (V)
Humidity 85% RH
Test Speed Up to 200 mm/s
Test Stroke 500 mm
Equipment Type Automatic Image Measuring Instrument
Machine Weight Approximately 420 kg Kilograms (kg)
Resolution 0.1 m
Capacity Multiple Sample Measurement Pcs/hr
Response Time Instantaneous (Depends on Processing) Seconds
Interface Type USB, LAN
Port Size Standard USB / LAN Ports
Frequency 50Hz Hertz (HZ)
Temperature 20C 2C (Operating) Celsius (oC)
Test Width 600 mm Millimeter (mm)
Application Precision Component Measurement, Quality Inspection
Specimen Size Max 600 x 500 mm Millimeter (mm)
Features High Accuracy, Motorized Stage, Auto Focus, CNC Control
Test Range 600 mm x 500 mm x 200 mm
Display Type Computer-based Digital Display
Power Supply AC 220V / 50Hz
Usage Industrial Measurement, Laboratory Analysis
Accuracy 2.8 + L/200 m %
Control Mode CNC Automatic
Dimension (L*W*H) 700MM*900MM*1650MM Millimeter (mm)
Max Height 200 mm (Z axis)
Measuring Range X: 600 mm, Y: 500 mm, Z: 200 mm Rankine

Data Export Format CSV, Excel, Image Formats
Lens Type Zoom Lens 0.7X-4.5X, Automatic Focusing
Stage Material Granite Base, Aluminum Alloy Frame
Operating Environment Dust-free, Temperature-controlled Room
Safety Features Emergency Stop Button, Overload Protection
Measurement Software Full-featured Image Measurement and Analysis Software Provided
Camera High-resolution Industrial Digital Camera (5.0MP or more)
Communication Interface USB 3.0, LAN, VGA/HDMI Output
Drive System Precision Ball Screw, Linear Guide
Lighting System Programmable LED Surface and Contour Illumination
Coordinate System XYZ Three-axis

Product Description

Instrument Operating Environment (Reference)

Temperature and Humidity

1)Temperature range 20-25 C, optimum 22 C

2)The range of humidity is 50%60%. The optimum humidity is 55%.

3)Maximum temperature change rate in computer room environment is 10 C/h

Calculating the heat dissipation in the computer room. To keep the computer system in the computer room operating in the optimum temperature and humidity space, it is necessary to calculate the computer.

Total heat dissipation in the room, including the total heat dissipation of machines in the room (ordinary lighting can be neglected)

1)Personnel heat dissipation: an average of 600 BTY/h per person

2)Room space heat dissipation: 50BTY/square foot

3)Future expansion of equipment (outline)

Air Dust Content

The computer room should be kept clean. There are no more than 45,000 impurities in the air of about 0.5 MLXPOV per cubic foot. If there is too much dust in the air, it is easy to cause equipment malfunction.

Atrial fibrillation

The flutter degree in the computer room shall not be higher than 0.5T. The vibration-producing machines in the computer room shall not be placed together. The flutter will cause bad contact between the mechanical parts and joints in the machine, resulting in abnormal operation of the machine, or the flutter of the measured objects, resulting in measurement errors.

Power Configuration

AC220V/AC110V

High-Accuracy Performance for Demanding Applications

With advanced optics, automated focusing, and a granite-based structure, this image measuring instrument offers outstanding precision with an accuracy rate of 2.8 + L/200 m. CNC control and XYZ axis motion ensure reliable, repeatable measurements, catering to precision component assessment and quality assurance in research labs and manufacturing floors alike.

User-Friendly Digital Interface and Reporting

The system comes equipped with intuitive, comprehensive software for image analysis and measurement. It supports easy data export in common CSV, Excel, and image file types. The computer-based digital display, USB 3.0, LAN connectivity, and VGA/HDMI output streamline both local and remote data access, visualization, and reporting.

FAQ's of Automatic Image Measuring Instrument:

Q: How does the automatic image measuring instrument achieve high measurement accuracy?

A: The instrument features a granite base for stability, a precision ball screw drive system, high-resolution digital camera, zoom lens, and motorized stage. Its advanced measurement software and automatic focusing further ensure precise and repeatable results with an accuracy of 2.8 + L/200 m.

Q: What types of components and specimens can be measured with this system?

A: This instrument accommodates single or multiple specimens up to 600 x 500 mm in size and 200 mm in height. It is suitable for a variety of precision components used in industrial measurement and laboratory analysis.

Q: When should the equipment be operated for optimal performance?

A: For best results, operate the instrument in a dust-free, temperature-controlled room maintained at 20C 2C, with humidity not exceeding 85% RH. Such an environment ensures the highest accuracy and consistency in measurement outcomes.

Q: Where can measurement data be exported from the system?

A: Measurement data can be exported directly from the provided software to CSV, Excel, and common image formats, allowing easy integration into quality control workflows, records, and reports for manufacturing or laboratory use.

Q: What is the process for measuring a specimen using this instrument?

A: First, position the specimen on the motorized granite base. Use the system's software to configure the measuring parameters and initiate the automated process. The programmable lighting and auto-focus ensure clear imaging, after which the software analyzes and outputs precise measurements.

Q: How does the safety system protect operators during instrument use?

A: The instrument includes essential safety features such as an emergency stop button and overload protection to prevent accidents and equipment damage during automated operation.

Q: What are the key benefits of using this automatic image measuring instrument?

A: Key benefits include high accuracy, rapid and automated measurements, robust data handling, user-friendly controls, and support for large or multiple specimen analysis. Its CNC automation and advanced optical capabilities optimize quality control and measurement efficiency.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Optical Measuring Machine' category

Optical Image Dimension Measurement Video Machine DH-5040F Price : 6239 USD ($)/Set Minimum Order Quantity : 1 Control Mode : Automatic/Manual Power Supply : AC 220V/50Hz Usage : Precision optical dimensional measurement Features : Noncontact measurement, automatic edge detection, video recording, programmable measurement routines Automation Grade : Fully automatic with manual override Accuracy : 2 m Test Range : 500 mm (X) 400 mm (Y) Display Type : Highresolution embedded 22inch monitor Specimen Size : Max 500 400 mm Measuring Range : X axis: 500 mm, Y axis: 400 mm, Z axis: 200 mm Equipment Type : Optical Image Dimension Measurement Video Machine Machine Weight : 260 kg Humidity : 20%~80% RH (noncondensing) Operating Voltage : 220V AC Test Speed : Up to 120 mm/s Number of Specimens : Single or Batch Mode Mounting Type : Benchtop Application : Precision measurement of dimensions in electronics, hardware, metal and precision parts Temperature : 10C~30C Interface Type : USB, VGA, RS232 Response Time : < 1 second Resolution : 0.001 mm Max Height : 200 mm (Z axis) Port Size : Standard USB, VGA, and Video ports Frequency : 50 Hz Capacity : Supports up to 10 kg Gas Pressure : 0.5~0.7 MPa Test Stroke : 500 mm Test Width : 400 mm Hardness : N/A (not applicable)

Send Inquiry

Large Scale CNC Type Video Measuring Machine Price : 14949.00 INR/Set Minimum Order Quantity : 1 Control Mode : CNC Automatic Power Supply : AC 220V 10%, 50/60Hz Usage : Lab and industrial metrology Features : Auto edge detection, 3D measurement, Program storage, Report output Automation Grade : CNC Automated Accuracy : 2.5 + L/200 m % Test Range : 0 1000 mm Display Type : Industrial LCD Monitor Specimen Size : Max 1200 x 1500 mm Millimeter (mm) Measuring Range : 1000 x 1500 x 200 mm (XYZ) Kelvin (K) Equipment Type : Large Scale CNC Video Measuring Machine Machine Weight : About 1800 kg Kilograms (kg) Humidity : 40% 70% RH (Noncondensing) Operating Voltage : AC 220V 10% Volt (V) Test Speed : 0.1 mm/s to 150 mm/s Number of Specimens : 1 (Single Test) Mounting Type : Floormounted Application : Precise dimensional measurement of large components Temperature : 20 C 2 C Celsius (oC) Interface Type : USB/RS232 Response Time : <0.5 seconds Seconds Resolution : 0.001 mm (1 micron) Max Height : 200 mm (Z Axis) Port Size : Standard USB/RS232 Frequency : 50/60 Hz Hertz (HZ) Capacity : Max Load 60 kg Kg Gas Pressure : 0.5 0.7 MPa mpa Test Stroke : XY Axis 1000 x 1500 mm Test Width : Up to 1200 mm Millimeter (mm)

Send Inquiry

Electronic CNC Control Fully-Auto Vision Image Measuring Machine Price : 13102.00 INR/Set Minimum Order Quantity : 1 Control Mode : Electronic CNC Control Power Supply : AC 220V 10%, 50/60 Hz Usage : Dimensional Inspection Features : Auto focus, CNC control, Vision image processing Automation Grade : Fully Automatic Accuracy : 2 m % Test Range : 0 mm 200 mm Display Type : HighResolution LCD Touchscreen Specimen Size : Max 200 mm 100 mm Millimeter (mm) Measuring Range : 200 mm 100 mm 150 mm (XYZ) Kelvin (K) Equipment Type : FullyAuto Vision Image Measuring Machine Machine Weight : 450 kg Kilograms (kg) Humidity : 40% 90% RH Operating Voltage : AC 220V Volt (V) Test Speed : Configurable, up to 250 mm/s Number of Specimens : Single or Multiple Mounting Type : Floor Stand Application : Precision measurement in electronics, hardware, plastics Temperature : 10 C 30 C Celsius (oC) Interface Type : USB, Ethernet, RS232 Response Time : < 1 s Seconds Resolution : 0.001 mm Max Height : 150 mm Port Size : USB 2.0, Ethernet Frequency : 50/60 Hz Hertz (HZ) Capacity : Varies by fixture, up to 10 kg Kg Gas Pressure : 0.5 0.8 MPa mpa Test Stroke : 200 mm (Xaxis), 100 mm (Yaxis) Test Width : 300 mm Millimeter (mm)

Send Inquiry

DCW Series Low Temperature Constant Temperature Bath for Viscometer Price : 458.0 USD ($)/Piece Minimum Order Quantity : 1 Control Mode : Digital microprocessor control Power Supply : AC 220V, 50Hz Usage : Laboratory temperature control for viscometer testing Features : Microprocessor temperature control, digital display, stainless steel chamber, low noise operation Automation Grade : Automatic temperature regulation Accuracy : 0.05C C Test Range : 15L Bath Volume Display Type : Digital LCD Specimen Size : Fits standard viscometer tubes Meter (m) Measuring Range : Dependent on viscometer model Rankine Equipment Type : Low Temperature Constant Temperature Bath Machine Weight : Approx. 18 kg Kilograms (kg) Humidity : 80% RH, noncondensing Operating Voltage : 220V AC Volt (V) Test Speed : Variable, typically 503000 rpm Number of Specimens : 1 (Viscometer Bath compatible) Mounting Type : Benchtop Application : Used for controlling temperature during viscosity testing with viscometers Temperature : 40C to 100C (adjustable) Celsius (oC) Interface Type : Simple button interface on front panel Response Time : 5 minutes to reach set temperature Minutes Resolution : 0.01C Max Height : Approx. 600 mm (including stand) Frequency : 50 Hz Hertz (HZ) Capacity : 15 liters Ltr
